SAMTEC DW0420LD811 High-Density Connector
The DW0420LD811 is a flexible connector with a 2.54 mm pitch, featuring gold or tin plating over phosphor bronze contacts. Designed for reliable interconnections in electronic and circuit board assemblies, it supports operating temperatures from -55°C to +125°C, ensuring durability and high performance. Its insulator material varies with series, including black glass-filled polyester, natural liquid crystal polymer, and other composites. This connector is RoHS compliant, solderable, and suitable for high-density applications requiring robust electrical contact and mechanical stability.
SAMTEC DW0420LD811 High-Density Connector Specifications:
- Pitch: 2.54 mm (0.100 inch)
- Material: Insulator - Black Glass-filled Polyester, Crystal Polymer, or other composites
- Terminal Material: Phosphor Bronze, Gold or Tin Plated
- Operating Temp Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Plating Thickness: 50 microns (1.27 μm) Gold over nickel
- RoHS Compliant: Yes
- Solderable: Yes, lead-free wave solder compatible
- Dimensions: Length varies with model, contact length approximately 1.009 inches (25.66 mm), width designed for high-density mounting
- Design features: Mechanical stability via recommended spacers, non-standard, non-returnable series
- Compatibility: Mates with various series including ZW, HW, DW, EW, supporting multiple options for height and pin count
