SAMTEC DW0813GD970 Flexible circuit connector
The DW0813GD970 is a flexible circuit board connector designed for high-reliability electronic connections, featuring black glass-filled polyester insulation and phosphor bronze terminals. It withstands temperatures from -55°C to +125°C with gold plating and up to +105°C with tin plating, offering RoHS compliance and lead-free solderability. This non-standard, customizable connector ensures secure mating and mechanical stability, ideal for applications requiring precise signal transmission and robust physical connection. Its versatile design supports various pin configurations and optional spacers for enhanced durability in demanding electronic assemblies.
SAMTEC DW0813GD970 Flexible circuit connector Specifications:
- Insulator Material: Black Glass-Filled Polyester for ZW, Natural Liquid Crystal Polymer for HW
- Terminal Material: Phosphor Bronze
- Plating: Gold (50 μin), Tin over Ni, Other platings available
- Operating Temperature Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- RoHS Compliant: Yes
- Solderability: Lead-free, wave solder compatible
- Number of Pins: Customizable, typical configurations support multiple pins
- Dimensions: Length varies with model, typical tail length approximately 2.54 mm (.100")
- Connection Style: Board Stacker, flexible supporting various height options
- Application: Suitable for high-reliability electronic connections, industrial automation, and assembly
- Certifications: RoHS compliant, UL listed (if applicable)
- Mechanical Stability: Recommended to use board spacers in applications with gold or selective gold plating
- Compatibility: Mates with compatible Samtec series connectors, supporting side or top mounting
- Environmental Resistance: Operates reliably in demanding temperature and mechanical environments
- Design Variation: Non-standard, customizable designs to meet specific application needs
- Additional Features: Supports different hole sizes and optional longer tails for secure physical attachment
