SAMTEC DW0815TD391 Edge Connector
The DW0815TD391 is a flexible edge connector designed for high-density board stacking applications. Featuring durable materials like black glass-filled polyester and liquid crystal polymer insulators, it supports operating temperatures from -55°C to +125°C with gold plating, ensuring reliable conductivity and corrosion resistance. This connector mates with various types, including ZW, HW, and DW series, and offers different height and pin configurations. Its RoHS compliance and lead-free solderability make it ideal for environmentally conscious, high-performance electronic assemblies.
SAMTEC DW0815TD391 Edge Connector Specifications:
- Insulator Material: Black Glass-Filled Polyester, Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Gold over Nickel (50 micro inches), Tin over Nickel
- Operating Temperature Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- RoHS Compliant: Yes, Lead-Free Solderable
- Number of Pins: Varies per configuration, up to 20 pins
- Connector Series: DW, ZW, HW - standardized for stacking
- Component Lengths: Approximately 0.89 inches (22.6 mm) to 1.09 inches (27.7 mm)
- Height Options: Multiple options available, typical around 0.25 inches (6.35 mm)
- Application: Board-to-board stacking, flexible connections in high-density electronics
- Notes: Mechanical stability enhanced with spacers, non-standard series, check specifications for configurations.
