SAMTEC DW1310GD500LL Flexible Board Stacker Connector
The SAMTEC DW series flexible board stacker connectors provide a reliable solution for stacking printed circuit boards in various industrial applications. These connectors are designed with a flexible construction to accommodate slight misalignments and thermal expansion. The DW-13-10-G-D-500-LL variant offers a .100" tail length, ensuring compatibility with a wide range of PCB layouts. RoHS compliant and operating within a temperature range of -55°C to +125°C, these connectors are suitable for demanding environments. Samtec recommends using mechanical board spacers for added stability, particularly in gold-plated applications.
SAMTEC DW1310GD500LL Flexible Board Stacker Connector Specifications:
- Mates with: SSW, SSQ, ESW, ESQ, CES, SLW, BSW, BCS, SSM, HLE, PHF
- No. Pins Per Row: Specify LEAD STYLE
- Lead Style: Specify LEAD STYLE
- Plating Option: Au or Sn over 50 µ" (1.27 µm) Ni
- Operating Temp Range: -55 °C to +125 °C (with Gold), -55 °C to +105 °C (with Tin)
- Tail Length: (5.08 mm) .200"
- Insulator Material: DW, EW, ZW: Black Glass Filled Polyester, HW: Natural Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Overall Length (OAL): (8.38 mm) .330"
- Stacker Height: (5.08 mm) .200"
- RoHS Compliant: Yes
- Lead Free Solderable: DW, EW, ZW: No, Lead Wave Only, HW: Yes
- File No: E111594
- Tail Length (mm): (1.40) .055
- Stacker Height (mm): (5.08) .200"
