SAMTEC DW1315TD225 Flexible Board Connector
This product is a flexible connector segment designed for dense electronic board stacking and interconnection applications. Made from high-quality insulator materials such as black glass filled polyester, liquid crystal polymer, and phosphor bronze terminal material with gold or tin plating, it operates within a temperature range of -55°C to +125°C. The connector features a compact size with a length of approximately 1.009 inches (25.65 mm), a width of 0.090 inches (2.29 mm), and a height around 0.064 inches (1.63 mm). It supports RoHS compliance and is suitable for custom board stacking configurations requiring reliable, high-performance connections with 2.54 mm pitch spacing. This non-standard component ensures robust interconnection in demanding electronic environments.
SAMTEC DW1315TD225 Flexible Board Connector Specifications:
- Insulator Material: Black Glass Filled Polyester, Liquid Crystal Polymer, or Natural Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze with Gold or Tin Plating
- Operating Temperature Range: -55°C to +125°C (Gold); -55°C to +105°C (Tin)
- Dimensions: Length approximately 1.009 inches (25.65 mm), Width approximately 0.090 inches (2.29 mm), Height around 0.064 inches (1.63 mm)
- RoHS Compliant: Yes
- Solderability: RoHS compliant, lead-free soldering
- Connector Type: Board Stacker, Flexible Segment
- Pitch: 2.54 mm
- Color: Black, Natural, or other as specified
- Application: Electronic interconnection, stacking, circuit board assembly
- Other Platings Available: Gold, Sn, Ni
- Temperature Ratings Supported: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Certifications: RoHS compliant, no lead wave soldering
- Standards: Non-standard, non-returnable component
