SAMTEC DW2511LD685 Flexible Circuit Connector
The DW2511LD685 is a flexible printed circuit connector with a 0.025 square millimeter cross-section, compatible with various stackers and cable mates. Made from Black Glass-filled Polyester for DW, EW, ZW series, and Liquid Crystal Polymer for HW series, it features phosphor bronze terminals with gold or tin plating for corrosion resistance. Operating temperature ranges from -55°C to +125°C depending on plating. This connector is RoHS compliant, solderable, and supports high-density configurations, ideal for advanced electronic and industrial applications requiring reliable, low-profile interconnections.
SAMTEC DW2511LD685 Flexible Circuit Connector Specifications:
- Insulator Material: Black Glass-filled Polyester for DW, EW, ZW; Liquid Crystal Polymer for HW
- Terminal Material: Phosphor Bronze
- Plating: Gold or Tin over Nickel
- Operating Temp Range: -55°C to +125°C (Gold), -55°C to +105°C (Tin)
- Dimensions: Length varies with model, typical tail length approximately 2.29 mm (0.090 inch), height approximately 7.87 mm (0.310 inch)
- Wire Cross-section: 0.025 sq mm
- RoHS Compliant: Yes
- Solderable: Yes (Wave only)
- Series Compatibility: DW, EW, HW, ZW
- Stacker and Cable Mates: Compatible with specific series, partial details available
- Mechanical Stability: Recommended mechanical board spacers for gold or selective gold plating
- Certification: RoHS compliant, meets industry standards
- Environmental Resistance: Supports high-temperature operation from -55°C to +125°C depending on plating
Buy the Buy Samtec Connector Series DW2511LD685 Part Number DW2511LD685 Online
Purchase the Samtec Flexible Circuit Connector DW2511LD685 online today to enhance your electronic projects with a durable, RoHS compliant, high-temperature rated connector. Designed for high-density applications, it features gold or tin plating for corrosion resistance and easy soldering. With its reliable performance across a temperature range of -55°C to +125°C and compatibility with various stackers and cable mates, this connector ensures your devices operate smoothly in demanding industrial and electronics environments. Take advantage of online exclusive offers and fast shipping now.
Order your Samtec Series DW2511LD685 connector today and ensure reliable high-density electronic connections with excellent temperature resilience.
Frequently Asked Questions
Where can I buy SAMTEC DW2511LD685?
You can click on the BUY or RFQ button to purchase DW2511LD685 from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part DW2511LD685?
You can download the DW2511LD685 datasheet or visit the SAMTEC website for support.
Who is the manufacturer of DW2511LD685?
SAMTEC
