SAMTEC DW3009TD510 Flexible PCB Connector
The product is a high-performance flexible connector designed for industrial applications, featuring a 0.025 sq mm cross-section, multi-material construction, and operating temperature range from -55°C to +125°C. It mates with various module types, including DW, EW, ZW, and HW series, and offers RoHS compliance and lead-free solderability. The connector incorporates durable phosphor bronze terminals with gold or tin plating for reliable electrical contact, suitable for PCB mounting, with specific mechanical spacer recommendations for enhanced stability. Its versatile design supports complex wiring and high-frequency signals, making it ideal for demanding industrial environments.
SAMTEC DW3009TD510 Flexible PCB Connector Specifications:
- Insulator Material: Black Glass Filled Polyester, Natural Liquid Crystal Polymer for HW
- Terminal Material: Phosphor Bronze with Gold or Tin Plating
- Plating: 50 microns (1.27 µm) Au over Ni or Sn
- Operating Temp Range: -55°C to +125°C (Gold), -55°C to +105°C (Tin)
- RoHS Compliant: Yes
- Solderability: Lead-Free, Wave-able
- Height Options: 1.009 inches (25.65mm), 1.016 inches (25.8mm)
- Connector Series: DW, EW, ZW, HW
- Connector Type: Stacker, Flexible PCB Connector
- Number of Pins: varies per series, up to 20 pins
- Connection Type: Board Stacker
- Design Features: Mechanical stability recommended with spacers in gold-plated applications
- Dimensions: Length varies with model, typical tail length approximately 0.090 inches (2.29mm)
- Certifications: RoHS Compliant
- Application: Industrial electronics, PCB-to-PCB connections, high-frequency systems
Buy the Samtec DW3009TD – Reliable Flexible Connectors for Industrial Applications
Enhance your industrial projects with the reliable Samtec Flexible PCB Connector Series DW3009TD. Designed for durability and high performance, it features RoHS compliance, versatile series options, and precise dimensions. This connector ensures stable connections in demanding environments, supporting up to 20 pins with gold or tin plating for excellent conductivity. Easy to install, it’s ideal for PCB-to-PCB wiring, high-frequency applications, and space-constrained designs. Purchase online today and ensure your electronics are equipped with trusted, durable connectors to improve performance and longevity.
Order your Samtec Series DW3009TD connector today and give your projects the dependable high-frequency and high-current capability they deserve.
