SAMTEC EW1514GD1000LL Edge Card Connector
The EW1514GD1000LL is a flexible, high-quality edge card connector designed for reliable connections on circuit boards. It features durable materials such as phosphor bronze with gold or tin plating, ensuring excellent conductivity and corrosion resistance. The connector accommodates a variety of pin configurations, with operating temperature ranges from -55°C to +125°C, and it complies with RoHS standards. Its construction includes insulator materials like black glass-filled polyester and natural liquid crystal polymer, making it suitable for demanding electronic applications requiring mechanical stability and precise signal integrity.
SAMTEC EW1514GD1000LL Edge Card Connector Specifications:
- Insulator Material: Black Glass-filled Polyester or Natural Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze with Gold or Tin Plating
- Operating Temp Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Plating: Au or Sn over Ni
- Dimensions: Fits 2.54 mm (0.100) inch pitch, length approximately 16.00 mm, height approximately 6.89 mm
- Number of Pins: Varies per configuration, specific to application
- RoHS Compliant: Yes
- Solderability: RoHS compliant, lead-free solder
- Color: Black insulator for ZW and DW styles, Natural for HW style
- Connector Style: Stacker type, suitable for board stacking applications
- Certifications: RoHS compliant, manufacturer standards met
- Temperature Range: -55°C to +125°C for gold plated, -55°C to +105°C for tin plated
- Mechanical Stability: Recommended to use mechanical board spacers for added strength
- Other Platings: Optional, consult datasheet for details
