SAMTEC FTSH10603FDV Micro Pitch Connector
The FTSH series connector offers high-density, right-angle surface-mount interconnect solutions with a micro pitch of 1.27 mm. Featuring black liquid crystal polymer insulators and phosphor bronze terminals with gold over nickel plating, these connectors support currents up to 3.4 A per pin. Designed for durability, they operate from -55 °C to +125 °C and offer optional shrouds, molded pick & place pads, and positive alignment features. Ideal for space-constrained, high-reliability electronic applications, they include various configurations for board and cable mates, with optional end shrouds and ejector shrouds available.
SAMTEC FTSH10603FDV Micro Pitch Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Shallower Au over 50 μm Ni
- Current Rating: 3.4 A per pin (2 pins powered)
- Operating Temperature Range: -55°C to +125°C
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Pitch: 1.27 mm
- Connector Style: Surface Mount, Right-Angle
- Max Lead Coplanarity: 0.10 mm (0.004 inch) for -DV and -MT options
- Dimensions vary based on configuration, with optional end and ejector shrouds
- Designed for high reliability, space saving, and easy PCB assembly
- Includes molded pick & place pads for automated assembly
- Available with positive alignment features and optional guides for precise mating
- Supports multiple configurations for board and cable mating, with optional flex shrouds
Buy the Samtec FTSH – Reliable Micro Pitch Surface Mount Connector for Industrial Applications
Enhance your electronic design with the reliable, high-density Micro Pitch Connector designed for space-constrained applications. Featuring gold-plated terminals, RoHS compliance, and operating from -55°C to +125°C, this surface mount connector offers excellent durability and easy PCB assembly with molded pick & place pads. Optional shrouds ensure secure mating, while advanced designs provide positive alignment for precise connections. Ideal for high-reliability systems, order online now and integrate robust, space-efficient connections into your industrial or consumer electronics projects with confidence.
Order your Samtec Series FTSH connector today and ensure high-density, reliable interconnections for your electronic projects with quick online availability.
Frequently Asked Questions
Where can I buy SAMTEC FTSH10603FDV?
You can click on the BUY or RFQ button to purchase FTSH10603FDV from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part FTSH10603FDV?
You can download the FTSH10603FDV datasheet or visit the SAMTEC website for support.
Who is the manufacturer of FTSH10603FDV?
SAMTEC
