SAMTEC FTSH12904LDV Micro pitch connector
The FTSH12904LDV is a precision surface-mount, micro pitch connector featuring a black liquid crystal polymer insulator and phosphor bronze terminals with a gold-over- nickel plating. Designed for high reliability in demanding industrial environments, it supports current ratings of 3.4 A per pin, operates within a temperature range of -55°C to +125°C, and complies with RoHS standards. This connector offers optional features like molded pick-and-place pads, high mating cycles, and various shroud options, ensuring flexibility for diverse PCB applications and maximizing product durability.
SAMTEC FTSH12904LDV Micro pitch connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Gold flash over 50 μin Nickel
- Current Rating: 3.4 A per pin (2 pins powered)
- Operating Temperature Range: -55°C to +125°C
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Pin Count Options: 2 to 25 positions
- Surface Mount Design with high coplanarity tolerance
- Optional molded pick-and-place pads and shroud options available
- Compatible with specific mating connectors like FFSD, CLP-DH, CLP-BE
- Connector dimensions and configurations vary by model, supporting multiple pin and style configurations
- Environmentally robust, suitable for industrial applications, with features supporting high mating cycles and reliability
Buy the Samtec FTSH12904LDV – Reliable Micro Pitch Connector for Industrial Applications
Enhance your PCB assembly with the high-quality Samtec Micro pitch connector series. Featuring liquid crystal polymer insulation, phosphor bronze terminals with gold plating, and support for high mating cycles. This surface mount connector operates from -55°C to +125°C, is RoHS compliant, and offers versatile configurations including optional shrouds and molded pick-and-place pads. Ideal for industrial equipment, automation systems, and high-reliability electronics, it ensures seamless connectivity, durability, and compliance for demanding manufacturing and engineering projects.
Order your Samtec FTSH12904LDV series high-performance surface-mount connector today and ensure your PCB assemblies benefit from durable, reliable connections in demanding industrial environments.
Frequently Asked Questions
Where can I buy SAMTEC FTSH12904LDV?
You can click on the BUY or RFQ button to purchase FTSH12904LDV from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part FTSH12904LDV?
You can download the FTSH12904LDV datasheet or visit the SAMTEC website for support.
Who is the manufacturer of FTSH12904LDV?
SAMTEC
