SAMTEC FTSH15001SDV Micro Pitch Connector
The FTSH15001SDV is a high-performance, surface-mount micro pitch connector designed for industrial applications, offering reliable electrical connections. Constructed with black liquid crystal polymer insulators and phosphor bronze terminals with gold over nickel plating, it supports currents up to 3.4 A per pin and operates from -55°C to +125°C. Its compact design includes molded pick-and-place pads, optional end shrouds, and low-profile options. Suitable for PCBs with precise coplanarity, this connector ensures durability and RoHS compliance in demanding environments.
SAMTEC FTSH15001SDV Micro Pitch Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Gold over 50 µin (1.27 µm) Nickel
- Current Rating: 3.4 A per pin
- Operating Temperature Range: -55°C to +125°C
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Model features: Molded pick-and-place pads, optional end shrouds, low-profile options, and precise coplanarity support.
- Pin Number Range: Various configurations including 2, 3, 5, 6, 8, 10, 13, 17, 20, 25 positions.
- Surface Mount Design: Suitable for PCB assembly with high reliability and minimal insertion force.
- Compatibility: Supports mating with specific female connectors, with optional lids and ejectors available.
- Temperature Tolerance: Stable from -55°C to +125°C, ensuring durable operation across environments.
- Certifications: RoHS compliant, built to industry standards for quality and safety.
Buy the Samtec FTSH15001SDV – Reliable Micro Pitch Connector for Industrial Applications
Enhance your electronic assemblies with the high-precision Samtec Micro Pitch Connector. Designed for PCB applications demanding reliability, this connector features gold-plated terminals, RoHS compliance, and a flexible range of configurations. Its compact, surface-mount design allows for easy installation with molded pick-and-place pads and optional shrouds for added protection. Supported by industry standards, it ensures consistent electrical performance from -55°C to +125°C, making it an ideal choice for demanding industrial and electronics manufacturing environments. Purchase online today for fast delivery and quality assurance.
Order your Samtec FTSH15001SDV series high-density surface-mount connector today and ensure secure, reliable connections for your industrial PCB projects.
Frequently Asked Questions
Where can I buy SAMTEC FTSH15001SDV?
You can click on the BUY or RFQ button to purchase FTSH15001SDV from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part FTSH15001SDV?
You can download the FTSH15001SDV datasheet or visit the SAMTEC website for support.
Who is the manufacturer of FTSH15001SDV?
SAMTEC
