SAMTEC HMTSW11209SS504 Board-to-Board Connector
The HMTSW11209SS504 is a high-quality, polarized board-to-board connector designed for flexible stacking arrangements in electronic assemblies. It features a black glass-filled polyester insulator, phosphor bronze contacts with gold plating, and supports operating temperatures from -55°C to +125°C. This connector offers multiple post heights and configurations, including straight and right-angle options, making it suitable for compact circuit designs requiring reliable electrical connections. RoHS compliant and capable of withstanding demanding industrial environments, it ensures long-lasting durability and consistent performance in intricate electronic systems.
SAMTEC HMTSW11209SS504 Board-to-Board Connector Specifications:
- Insulator Material: Black Glass Filled Polyester
- Terminal Material: Phosphor Bronze
- Plating: 50 µin (1.27 µm) Gold
- Operating Temperature Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- RoHS Compliant: Yes
- Post Height Options: Specify in inches, increments of 0.005" (0.13 mm), typical range up to 1.29" (32.76 mm)
- Number of Positions: Varies, with configurations for 10, 12, 14, 16, 18, 20, 22, 24 post options
- Design Features: Polarized, available in straight and right-angle versions, suitable for high-density PCB applications
- Connector Style: Board-mount, multi-position, stackable with customizable post heights
- Application: Ideal for electronic equipment requiring reliable, space-efficient connections with high durability
Buy the Samtec Series MTSW Connectors: HMTSW11209SS504
Purchase the Samtec HMTSW11209SS504 board-to-board connector online today and ensure reliable electrical connections for your electronic projects. Designed with high-quality materials including gold-plated phosphor bronze contacts and a durable polyester insulator, this connector offers excellent thermal and mechanical stability from -55°C to +125°C. Its versatile configurations include straight and right-angle versions, with customizable post heights to suit various space constraints. RoHS compliant and engineered for lasting performance, the HMTSW11209SS504 is ideal for compact, high-density electronic designs demanding dependable, efficient connectivity solutions.
Get Samtec HMTSW11209SS504 today—built for precise fits and long-lasting durability in electronic assemblies.
