Samtec HTSW10206SD PCB Header
This high-quality through-hole header connector features a 2-position configuration with 2.54 mm (0.100 inch) pin centers, ideal for PCB connections. Made from black glass-filled polyester or natural liquid crystal polymer, it offers reliable electrical performance with phosphor bronze terminals plated with gold or tin over nickel. Capable of withstanding temperatures from -55°C to +125°C, it is RoHS compliant and suitable for various industrial applications. The connector is designed for lead-free soldering and includes options for elevated right-angle configurations and locking leads, ensuring versatile installation and durability.
Samtec HTSW10206SD PCB Header Specifications:
- Pin centers: 2.54 mm (0.100 inch), 5.08 mm (0.200 inch)
- Material: Black glass-filled polyester (TSW), Natural liquid crystal polymer (HTSW)
- Terminal Material: Phosphor bronze with gold or tin over 50 micro-inch nickel plating
- Operating temperature range: -55°C to +125°C
- Voltage ratings: 550 VAC mated with SSW; 500 VAC with other configurations
- RoHS compliant: Yes
- Lead-free solderability: Yes
- Height options: Elevated right-angle and standard configurations
- Designed for PCB mounting, with optional locking leads and shunt configurations
- Connector options: Various lengths, styles, and plating for different industrial applications
Buy the Samtec Series TSW PCB Header: HTSW10206SD
Discover the reliable performance of the Samtec Series TSW HTSW10206SD PCB header, designed for optimized PCB connections in industrial and electronic projects. This 2-position through-hole connector features a 2.54 mm pitch, RoHS compliance, and options for elevated right-angle installation, ensuring a secure fit and durable solder connections. Made from high-quality materials with gold or tin plating, it withstands temperature ranges from -55°C to +125°C. Whether for manufacturing or repair, purchase this dependable connector online today for efficient assembly and lasting reliability.
Order your Samtec Series TSW HTSW10206SD today and give your projects the dependable quality they deserve with this versatile through-hole connector.
Frequently Asked Questions
Where can I buy Samtec HTSW10206SD?
You can click on the BUY or RFQ button to purchase HTSW10206SD from an authorized Samtec distributor.
How do I troubleshoot issues or seek technical support for part HTSW10206SD?
You can download the HTSW10206SD datasheet or visit the Samtec website for support.
Who is the manufacturer of HTSW10206SD?
Samtec
