SAMTEC HTSW20317TMS Pin Header
The HTSW20317TMS is a high-quality, through-hole pin header designed for industrial applications, featuring a black glass-filled polyester insulator, phosphor bronze terminals with gold or tin plating. It supports operating temperatures from -55°C to +105°C and is RoHS compliant, making it suitable for environmentally conscious projects. The header offers various options including right-angle, shunt, and locking leads, with voltage ratings up to 550 VAC when mated with compatible connectors. Ideal for PCB connections demanding durability and reliable electrical performance.
SAMTEC HTSW20317TMS Pin Header Specifications:
- Insulator Material: Black Glass Filled Polyester
- Terminal Material: Phosphor Bronze
- Plating: Gold or Sn over 50 µ
- Voltage Rating: 550 VAC with SSW, 500 VAC with WBCS or ESQ, 450 VAC with RA/-RE, 400 VAC with CES
- Operating Temperature Range: -55°C to +105°C (Tin plating), -35°C to +125°C (Gold versions)
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Current Rating: Up to 15.2 A, supports multiple configurations with different current capacities
- Connector Type: Through-hole pin header with various options including right-angle, locking leads, and shunt connections
- Supported Series: SSW, SSQ, SSM, ESW, ESQ
- Physical Dimensions: Pin center distances of 2.54 mm (0.100 inches) and 5.08 mm (0.200 inches), with lengths and styles configurable
- Special Options: Elevated right-angle, locking leads, optional shunts, and custom lengths available
- Certification and quality standards can be verified at www.samtec.com/quality
