SAMTEC IDSD10D1200G IDC Ribbon Socket
The IDSD-10-D-12.00-G from Samtec is a 0.1 inch (2.54mm) pitch, double-row IDC ribbon socket cable assembly with a slim body design. It features a 20-position receptacle with a 12-inch grey cable on each end, suitable for connecting various connectors such as TSW, MTSW, TSM, EJH, PHT, HMTSW, HTSW, HW, DW, EW, ZW, MTLW, TST, HTST, ZST, BST, and EJH. Made from black glass-filled polyester insulator, it has phosphor bronze contacts with 10-micrometer gold plating, paired with 28 AWG, 7/36 stranded tinned copper wire. The operating temperature ranges from -40°C to 105°C, with a current rating of 3.4A per pin when one position is powered per row. Contact resistance is 15 milliohms, and it’s UL recognized, ideal for industrial and electronic equipment applications.
SAMTEC IDSD10D1200G IDC Ribbon Socket Specifications:
- Pitch: 0.1 inch (2.54mm)
- Number of positions: 20
- Cable length: 12 inches (per end)
- Connector type: IDC ribbon socket
- Contact Material: Phosphor Bronze
- Plating: 10-micrometer gold over nickel
- Wire Type: 28 AWG, 7/36 stranded tinned copper
- Insulator Material: Black glass-filled polyester
- Temperature Range: -40°C to +105°C
- Contact Resistance: 15 milliohms
- Current Rating: 3.4A per pin (single row powered)
- Rated Voltage: Compatible with industrial voltage levels
- UL Recognition: E111594
- Compatibility: Multiple connector types listed
- RoHS Compliant: Yes
Buy the Buy Samtec IDC Socket Part Number IDSD10D1200G Online
Purchase the Samtec IDC Ribbon Socket with 20 positions and 12-inch grey cable online today. This high-quality connector features gold-plated contacts, a durable glass-filled polyester insulator, and is rated for temperatures from -40°C to 105°C. Its design ensures reliable performance in industrial and electronic applications, offering current ratings of 3.4A per pin. With UL recognition and RoHS compliance, this versatile connector supports a wide range of connector types and is perfect for demanding environments, ensuring secure and durable electrical connections.
Buy Samtec IDSD10D1200G now and experience reliable high-current connections with its robust, glass-filled polyester insulator and gold-plated contacts.
Frequently Asked Questions
Where can I buy SAMTEC IDSD10D1200G?
You can click on the BUY or RFQ button to purchase IDSD10D1200G from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IDSD10D1200G?
You can download the IDSD10D1200G datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IDSD10D1200G?
SAMTEC
