SAMTEC IJ504050LS1TR High-Frequency Edge Contact
The IJ5 series is a high-frequency, high-speed edge rate contact system suitable for PCB applications. Made with copper alloy contacts plated with gold or tin, it supports frequencies up to 55 GHz and data rates up to 17.0 Gbps. The contact system features a black LCP insulator and is compliant with RoHS standards. Designed for vertical applications, it offers a contact resistance below 34 mΩ and an insulation resistance exceeding 35,000 MΩ. Operating temperatures range from -55°C to +125°C, with complete test data and PCB layout recommendations available on the manufacturer website.
SAMTEC IJ504050LS1TR High-Frequency Edge Contact Specifications:
- Operating Temp Range: -55°C to +125°C
- Contact Material: Copper Alloy
- Plating: Au or Sn over Ni
- Dielectric Material: Black LCP
- Frequency Support: up to 55 GHz
- Data Rate: up to 17.0 Gbps
- Insulation Resistance: >35,000 MΩ
- Contact Resistance: Center <34 mΩ, Outer <7 mΩ
- Current Rating: 4.4 A per pin, 2.36 A per pin adjacent pins powered
- Sleeve Material: Black LCP
- RoHS Compliant: Yes
- Processing: Lead-Free, Solderable
- Mounting: Vertical orientation, multiple stack heights available
Buy the Samtec IJ5 Series – Reliable High-Frequency Contact for Industrial Applications
Enhance your PCB connections with the high-frequency edge contact system designed for ultra-fast data transmission up to 17 Gbps and frequencies of 55 GHz. Crafted with durable copper alloy contacts and gold or tin plating, this reliable component delivers outstanding electrical performance, low contact resistance, and excellent insulation consistency. Its RoHS-compliant black LCP insulator ensures durability across wide temperature ranges from -55°C to +125°C. Order online now to upgrade your electronic assemblies with proven quality and precise specifications for demanding industrial applications.
Order your Samtec IJ5 Series high-speed edge contact today and ensure your PCB assemblies achieve top performance with unmatched reliability.
Frequently Asked Questions
Where can I buy SAMTEC IJ504050LS1TR?
You can click on the BUY or RFQ button to purchase IJ504050LS1TR from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IJ504050LS1TR?
You can download the IJ504050LS1TR datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IJ504050LS1TR?
SAMTEC
