SAMTEC IP504050LS1TR RF High Isolation Plug
The RF-13 is a high isolation RF plug designed for advanced high-frequency applications. Featuring a copper alloy shell and black LCP insulator material, it offers excellent dielectric and structural integrity. With gold or tin plating over a nickel layer, it provides reliable electrical contacts. Capable of handling current ratings up to 2.36A per pin and supporting frequencies up to 152 Gbps, the RF-13 ensures low insertion loss, high return loss, and excellent shielding with isolation levels exceeding 70 dB. Suitable for demanding RF and microwave systems, it complies with RoHS standards and is IP5 rated for rugged environments.
SAMTEC IP504050LS1TR RF High Isolation Plug Specifications:
- Shell Material: Copper Alloy
- Insulator Material: Black LCP
- Contact Material: Copper Alloy
- Plating: Au or Sn over 50μ'' (1.27 μm) Ni
- Current Rating: 2.36 A per pin
- Operating Temp Range: -55°C to +125°C
- Dielectric Withstanding Voltage: 600 VAC (IP5), 190 VAC (IP5-RA)
- Working Voltage: 200 VAC (IP5), 190 VAC (IP5-RA)
- Insertion Loss: 3 dB at 10.5 GHz
- Return Loss: 15 dB at 5.5 GHz
- VSWR: 1.4 at 10.8 GHz
- Isolation: >70 dB at 7.6 GHz
- RoHS Compliant: Yes
- IP5 Rating: Yes
Buy the Buy Samtec RF Plug Part Number IP504050LS1TR Online
Purchase the Samtec RF High Isolation Plug IP504050LS1TR online today and enjoy exceptional performance in RF and microwave applications. Engineered with durable copper alloy shells and black LCP insulators, it offers superior dielectric properties and excellent shielding. With gold or tin plating over nickel, it ensures reliable electrical contacts capable of handling frequencies up to 152 Gbps and currents up to 2.36A per pin. Its compact design, high isolation levels, and compliance with RoHS standards make it the preferred choice for professional RF and microwave system integrators seeking proven, high-quality connectors.
Buy Samtec IP504050LS1TR now and experience unmatched reliability and performance in high-frequency RF systems.
Frequently Asked Questions
Where can I buy SAMTEC IP504050LS1TR?
You can click on the BUY or RFQ button to purchase IP504050LS1TR from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IP504050LS1TR?
You can download the IP504050LS1TR datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IP504050LS1TR?
SAMTEC
