SAMTEC IPS110501SD Industrial Connector
The IPS1-125-01-L-D series is a versatile 50-position, two-row connector designed for industrial and electronic applications. It features individually shrouded contacts for enhanced electrical and mechanical protection, with optional locking clips for secure connections. Made with black liquid crystal polymer insulators and phosphor bronze contacts plated with tin or gold, it supports high current ratings up to 48A and voltage ratings up to 098 VDC. The connectors accommodate both through-hole and surface mount processes, with an operating temperature range from -55°C to +125°C, suitable for demanding environments.
SAMTEC IPS110501SD Industrial Connector Specifications:
- Number of positions: 50
- Number of rows: 2
- Contact Material: Phosphor Bronze
- Plating: Sn or Au over 30-50 µ
- Insulator Material: Black Liquid Crystal Polymer (LCP)
- Operating Temperature Range: -55°C to +125°C
- Current Rating: Up to 48A per contact
- Voltage Rating: Up to 098 VDC
- Insertion Depth: 4.70 mm (0.185")
- Mounting: Both Through-Hole and Surface Mount options available
- Features: Individually shrouded contacts, optional locking clip
- Design: Standard sizes, customizable options, non-standard sizes available
- Compliance: Meets industry standards and recognitions, subject to change without notice
Buy the Samtec Series IPS1 Connector: IPS1-125-01-L-D
Enhance your electronic systems with the Samtec Series IPS1-125-01-L-D industrial connector. Featuring 50 positions, shrouded contacts, and high current capacity, it ensures secure and reliable connections in demanding environments. Compatible with both SMT and through-hole processes, these connectors support operating temperatures from -55°C to +125°C, making them ideal for rugged industrial applications. Secure your equipment with this easy-to-mount, durable connector available for online purchase, providing quality and reliability for your projects.
Order your Samtec Series IPS1-125-01-L-D connector today and ensure reliable, high-current connections for your industrial and electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC IPS110501SD?
You can click on the BUY or RFQ button to purchase IPS110501SD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IPS110501SD?
You can download the IPS110501SD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IPS110501SD?
SAMTEC
