SAMTEC IPT110501LD Power Connector
The IPT1 series are shrouded power connectors designed for high current applications with a temperature range of -55°C to +125°C, featuring phosphor bronze contacts with optional gold or tin plating, offering reliable electrical and mechanical protection. These connectors support various mounting options, including through-hole, right-angle, and surface mount, with a maximum current rating of 5.9A per contact. They include features like individual shrouding, locking options, and compliance with RoHS standards, making them suitable for industrial power, automation, and electronic device applications.
SAMTEC IPT110501LD Power Connector Specifications:
- Insulator Material: Black LCP
- Contact Material: Phosphor Bronze
- Plating: Sn or AU over 50" (1.27 um) Ni
- Operating Temp Range: -55°C to +105°C with Tin, -55°C to +125°C with Gold
- Insertion Depth: 3.81 mm to 6.48 mm
- Wiping Distance: 0.38 mm
- Voltage Rating: 775 VAC / 1095 VDC
- Standard Creepage: 2.49 mm
- Clearance: 1.91 mm (without -LC), 0.91 mm (with -LC)
- RoHS Compliant: Yes
- Current Rating: 5.9A per contact
- Lead-Free Solderable: Yes
- Mounting Options: Through-hole, right-angle, surface mount
- Pin Count: 10, 15, 20, 25
- Number of positions: 100
- Additional features: Individually shrouded contacts, locking clip option, polarized for one position, lockable
- Certifications: Recognitions on www.samtec.com/quality
Buy the Samtec IPT1 – Reliable Power Connectors for Industrial Applications
Order the Samtec IPT1 power connectors online today for dependable performance in high-current industrial applications. These connectors feature individual shrouding, multiple mounting options, and superior contact materials for enhanced electrical and mechanical protection. Designed for excellent temperature resistance up to 125°C, they support RoHS compliance and are suitable for automation, power distribution, and electronic device integration. Secure your power connections with this reliable, corrosion-resistant, and high-quality connector series that ensures long-term durability and safety in demanding environments.
Get Samtec IPT1 series connectors today—built for precision, high current capacity, and long-lasting durability in power and automation systems.
Frequently Asked Questions
Where can I buy SAMTEC IPT110501LD?
You can click on the BUY or RFQ button to purchase IPT110501LD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IPT110501LD?
You can download the IPT110501LD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IPT110501LD?
SAMTEC
