SAMTEC MMT11001SSH High-Density PCB Connector
The MMT-110-01-L-SH is a compact surface-mount connector designed for high-reliability PCB applications, featuring a 2.00 mm pitch, gold or tin plating, and available with alignment pins and locking clips. Constructed with black Liquid Crystal Polymer insulator and phosphor bronze contacts, it supports a temperature range from -55°C to +125°C with gold plating and up to +105°C with tin plating. This versatile connector supports single or double row configurations, suitable for surface mount and mixed technology applications. RoHS compliant, it ensures environmentally responsible manufacturing. Durable, precise, and easy to assemble, this connector is ideal for complex electronics requiring reliable connections.
SAMTEC MMT11001SSH High-Density PCB Connector Specifications:
- Pitch: 2.00 mm (.0787 inches)
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating Options: Gold flash or Matte Tin over 50 p" Ni
- Operating Temperature Range: -55°C to +125°C with Gold plating, -55°C to +105°C with Tin plating
- RoHS Compliant: Yes
- Number of Positions: varies (e.g., 1, 2, 3, 4, 5, 6, 8, 10, 12, 20, 30, 40, 50, 60, 80, 100, 120, 150, 200, 250, 300)
- Application Compatibility: Surface mount and mixed technology, suitable for single or double row configurations
- Additional Features: Alignment pins, locking clips, molded pick & place pads, optional board mates and cable mates
- Dimensions: Pitches of 2.00 mm, length varies with number of positions, standard options include 1, 2, 3, 4, 5, 6, 8, 10, 12, 20, 30, 40, 50, 60, 80, 100, 120, 150, 200, 250, 300 positions
- Certifications: RoHS compliant, other recognitions available on www.samtec.com/quality
Buy the Samtec Series MMT: PCB Connector 2.00 mm Pitch - MMT11001SSH
Experience reliable performance with the Samtec MMT11001SSH connector, designed for high-density PCB applications with a 2.00 mm pitch, gold or tin plating, and RoHS compliance. Its black Liquid Crystal Polymer insulator and phosphor bronze contacts ensure longevity and optimal electrical performance in demanding environments. Suitable for surface-mount and mixed technology, it supports multiple configurations with optional features like alignment pins, locking clips, and pick & place pads for easy assembly. Perfect for electronics requiring durable, high-quality connections, available for online purchase for convenience and speed.
Get Samtec MMT11001SSH today—built for precision, durability, and reliable PCB connections in your electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC MMT11001SSH?
You can click on the BUY or RFQ button to purchase MMT11001SSH from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part MMT11001SSH?
You can download the MMT11001SSH datasheet or visit the SAMTEC website for support.
Who is the manufacturer of MMT11001SSH?
SAMTEC
