SAMTEC MMT13502SMSH Edge Card Connector
The MMT Series edge card connectors are designed for high-reliability surface mount and mixed technology applications. Featuring a 2.00 mm pitch and available with optional gold or matte tin plating, these connectors support a range of configurations including single or double row. They accommodate various PCB layouts and include optional features like alignment pins, locking clips, and molded pick & place pads for easy assembly. Operating in temperatures from -55°C to +125°C, they meet RoHS compliance and are suitable for demanding electronic systems requiring secure, versatile connections.
SAMTEC MMT13502SMSH Edge Card Connector Specifications:
- Pitch: 2.00 mm (0.0787 inch)
- Material: Black Liquid Crystal Polymer insulator, Phosphor Bronze terminals
- Plating: Au (Gold) or Sn (Tin) over 50 μin Ni (1.27 μm)
- Operating Temperature Range: -55°C to +105°C with Tin, -55°C to +125°C with Gold
- RoHS Compliant: Yes
- Max Thickness: 0.004 inch (0.1016 mm)
- Cable Support: Optional cable mates available
- Surface Mount and mixed technology options
- Configurations: Single or double row, various pin counts
- Additional features: Alignment pins, locking clips, molded pick & place pads
- Applications: High-reliability electronic assemblies, PCB-to-board connections
Buy the Samtec Series MMT Edge Card Connector: MMT13502SMSH
Purchase the Samtec Series MMT13502SMSH edge card connector online today. This high-reliability connector features a 2.00 mm pitch, optional gold or tin plating, and supports various configurations including single or double row. Designed for surface-mount and mixed technology applications, it offers excellent thermal performance from -55°C to +125°C and meets RoHS standards. With optional features like alignment pins, locking clips, and molded pick & place pads, this connector guarantees secure and efficient PCB-to-board connections, ideal for demanding electronic systems.
Order your Samtec Series MMT13502SMSH high-density edge connector today and ensure reliable, versatile connections for your electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC MMT13502SMSH?
You can click on the BUY or RFQ button to purchase MMT13502SMSH from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part MMT13502SMSH?
You can download the MMT13502SMSH datasheet or visit the SAMTEC website for support.
Who is the manufacturer of MMT13502SMSH?
SAMTEC
