SAMTEC PCIELP0101SDVAKTR PCIe Edge Card Connector
The PCIE-LP Series low-profile edge card connectors are PCI Express® Gen 4 compliant, supporting configurations of one, four, eight, and sixteen links. They feature Edge Rate® contacts on a 1.00 mm pitch, optimized for signal integrity. With a low profile of 8 mm—3 mm thinner than standard connectors—they increase vertical space in chassis, enabling better airflow and routing. Designed for space-constrained or non-standard applications, they provide high-speed data transfer at 16 GT/s, ensuring low latency, power efficiency, and reliable transmission in demanding electronic systems.
SAMTEC PCIELP0101SDVAKTR PCIe Edge Card Connector Specifications:
- Connector Type: PCI Express® Gen 4 compliant Edge Card connector
- Contact Material: Edge Rate® contact system, Phosphor Bronze, Au or Sn plating
- Pitch: 1.00 mm (.0394 inch)
- Profile Height: 8 mm (3 mm thinner than standard 11 mm)
- Signal Support: 1, 4, 8, 16 links
- Supported Data Rate: 16 GT/s
- Insulator Material: Black Nylon, LCP
- Operating Temperature: -55°C to +125°C
- Card Insertion Depth: 7.65 mm (.301 inch)
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Application: High-speed data transfer, space-constrained electronic systems
- Compatibility: PCI Express® protocol, PCIe Gen 4
Buy the Samtec Series PCIe Edge Card Connector: PCIELP0101SDVAKTR
Purchase the Samtec PCIe Edge Card Connector today—engineered for high-speed PCI Express® Gen 4 performance with a low profile of just 8 mm. This space-saving connector supports 1, 4, 8, and 16 links with 1.00 mm pitch for versatile bandwidth needs. Its Edge Rate® contact system ensures excellent signal integrity, durability, and resistance to damage during unmating. Ideal for compact electronic systems requiring reliable high-speed data transfer at 16 GT/s, this connector provides optimal airflow, easy installation, and long-term performance.
Get Samtec PCIELP0101SDVAKTR today—built for precision, durability, and high-speed data performance in space-constrained applications.
Frequently Asked Questions
Where can I buy SAMTEC PCIELP0101SDVAKTR?
You can click on the BUY or RFQ button to purchase PCIELP0101SDVAKTR from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part PCIELP0101SDVAKTR?
You can download the PCIELP0101SDVAKTR datasheet or visit the SAMTEC website for support.
Who is the manufacturer of PCIELP0101SDVAKTR?
SAMTEC
