SAMTEC PCIELP1601SDVAK PCI Express Connector
The PCIE-LP Series low-profile edge card connector complies with PCI Express® Gen 4 standards, supporting 1, 4, 8, and 16 links for diverse bandwidth needs. It features Edge Rate® contacts on a 1.00 mm pitch, optimized for signal integrity, with an ultra-low profile of 8 mm—3 mm thinner than standard connectors with a 3.50 mm contact wipe. Designed for space-constrained applications, it offers high data transfer speeds up to 16 GT/s, ensuring low latency and power efficiency. Rugged contact systems reduce crosstalk, improve cycle life, and maintain impedance control for reliable, durable connections in high-performance systems.
SAMTEC PCIELP1601SDVAK PCI Express Connector Specifications:
- Pitch: 1.00 mm (0.0394 inches)
- Profile Height: 8 mm (3 mm thinner than standard connectors)
- Contact Material: Edge Rate® contacts
- Contact Plating: Gold over nickel
- Number of Links: 1, 4, 8, 16
- Supported Data Rate: Up to 16 GT/s
- Operating Temperature: -55°C to +125°C
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Card Insertion Depth: 7.65 mm (0.301 inches)
- Connector Type: Edge card connector
- Application: PCI Express 4.0 compliant high-speed interconnects
- Mounting Options: Card edge or PCB mount
- RoHS and REACH Compliant
Buy the Buy Samtec PCIE-LP1601SDVAK Part Number PCIE-LP1601SDVAK Online
Experience high-performance, space-saving PCI Express connections with the Samtec PCIE-LP Series connector. Designed for PCI Express 4.0 compliance, it supports up to 16 links, ensuring fast data transfer rates of up to 16 GT/s. Its ultra-low profile of 8 mm makes it ideal for compact, high-density electronic systems, providing excellent signal integrity, durability, and easy routing. Choose this reliable connector for demanding applications requiring minimal space and maximum performance, backed by Samtec's quality and engineering excellence.
Get Samtec PCIE-LP1601SDVAK today—designed for space-efficient, high-speed PCI Express connections with durability and optimal signal integrity.
Frequently Asked Questions
Where can I buy SAMTEC PCIELP1601SDVAK?
You can click on the BUY or RFQ button to purchase PCIELP1601SDVAK from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part PCIELP1601SDVAK?
You can download the PCIELP1601SDVAK datasheet or visit the SAMTEC website for support.
Who is the manufacturer of PCIELP1601SDVAK?
SAMTEC
