SAMTEC SFMH12002LDLC SMT Connector
The SFMH-120-02-L-D-LC is a high-quality SMT header connector featuring a coplanarity of 0.004 inches and a contact resistance of 15 milliohms. Made with black liquid crystal polymer insulation and phosphor bronze terminals, it supports a maximum current of 26 A per pin within a temperature range of -55°C to +125°C. The connector offers various pin options, with plated gold over nickel, and is RoHS compliant. Its insertion depth varies from 0.132 to 0.180 inches, designed for reliable surface-mount applications. Ideal for electronic assemblies requiring durability and precision connections.
SAMTEC SFMH12002LDLC SMT Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn arAu over Ni
- Current Rating: 26 A per pin
- Operating Temp Range: -55°C to +125°C
- RoHS Compliant: Yes
- Contact Resistance: 15 mΩ
- Insertion Depth: 0.132 to 0.180 inches
- Surface Mount Lead Coplanarity: 0.004 inches
- Pin Options: 5, 10, 15, 20, 25
- Number of Positions: (Position count + 4) x 1.27 mm
- Material: Liquid Crystal Polymer insulation
- Gold Flash on Tail: Optional
- Applicable for Through-Hole and Surface Mount configurations
- High reliability with durable gold plating for minimal contact resistance
Buy the Buy Samlec SFMH120-02-L-D-LC Part Number SFMH120-02-L-D-LC Online
Order the Samlec SFMH-120-02-L-D-LC today to experience high-performance surface-mount connectors with gold-plated contacts, robust construction, and compatibility with various pin configurations. Designed for reliable electrical connections in demanding electronic assemblies, this connector ensures long-lasting durability and excellent contact resistance. Whether you need through-hole or surface-mount options, the SFMH series offers precision engineering, RoHS compliance, and versatile configurations. Shop online now to enhance your electronic projects with quality you can trust, backed by quick delivery and excellent support.
Get Samlec SFMH120-02-L-D-LC today—built for durability and precision electronic connections.
Frequently Asked Questions
Where can I buy SAMTEC SFMH12002LDLC?
You can click on the BUY or RFQ button to purchase SFMH12002LDLC from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SFMH12002LDLC?
You can download the SFMH12002LDLC datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SFMH12002LDLC?
SAMTEC
