SAMTEC SFML120T2SDA High-Density Rugged Connector
The Tiger Eye high-density connector series offers rugged, polarized, keyed surface-mount or through-hole options with an innovative four-row design. Features include screw-down locking clips, friction latching, weld tabs, and IDC cable locking for increased strain relief. Available in single or double row configurations, it supports 28 and 30 AWG PVC or Teflon wires. Suitable for demanding electronic and industrial applications, it provides reliable electrical connections with operating voltages up to 250VAC, high cycle durability, and various plating options for enhanced corrosion resistance.
SAMTEC SFML120T2SDA High-Density Rugged Connector Specifications:
- Pitch: 1.27 mm (0.050 inch)
- Operating Voltage: 250VAC
- Operating Cycles: 10,000 cycles
- Contact Material: BeCu with Au or Sn over plating
- Surface Mount or Through-Hole options available
- Number of Pins: Varied (e.g., 3, 4, 6, 8...)
- Wire Gauge: 28 and 30 AWG PVC or Teflon wires
- Insulator Material: Black LCP
- Contact Plating: Gold (ELP™) or Tin
- Keyed and polarized for reliable mating
- Locking options: screw-down, friction, weld tab, IDC locking
- Cable components and tooling available
- Dimensions vary based on configuration, supporting rugged industrial use
Buy the Samtec Series Tiger Eye Connector: SFML120T2SDA
Order the Samtec Tiger Eye SFML120T2SDA connector online today for robust, high-density electronic connections. Designed for industrial applications, it offers polarized, keyed mounting options with screw-down, friction, and weld tab locking features. Compatible with 28-30 AWG wires, it provides reliable electrical contact, high cycle durability, and corrosion-resistant plating. Featuring both surface-mount and through-hole configurations, this connector ensures secure, rugged connections for demanding environments. Buy online now to ensure your projects have dependable, long-lasting electrical components.
Get Samtec Tiger Eye SFML120T2SDA today—built for rugged industrial electronics and reliable high-density connections.
Frequently Asked Questions
Where can I buy SAMTEC SFML120T2SDA?
You can click on the BUY or RFQ button to purchase SFML120T2SDA from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SFML120T2SDA?
You can download the SFML120T2SDA datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SFML120T2SDA?
SAMTEC
