SAMTEC SHF10501LDSM Surface-Mount Connector
The SHF series and ESHF series connectors are high-quality, surface-mount terminal blocks designed for reliable electrical connections in industrial and electronic applications. Made with black liquid crystal polymer insulators and phosphor bronze terminals, these connectors feature tin or gold plating over 50 microinches of nickel. Operating within a temperature range of -55°C to +125°C, they are RoHS compliant and solderable, with a maximum coplanarity of 0.10 mm for SMT mounting. Various sizes, pin counts, and options ensure compatibility across diverse electronic assemblies and industrial systems.
SAMTEC SHF10501LDSM Surface-Mount Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50p" Ni
- Operating Temp Range: -55°C to +125°C
- RoHS Compliant: Yes
- Processing: Lead-Free Solderable: Yes
- SMT Lead Coplanarity: 0.10 mm max
- No. of Pins: varies with model, standard sizes 13, 17, 20, 25
- Pin Pitch: 1.27 mm (.050")
- Length Options: Different lengths available, non-standard options. Some sizes are non-returnable.
- Compatibility: ESHF mates with EHF series; note strain relief options
- Processing note: Surface retention, polar positions, and optional features vary by model
- Certification: Multiple recognitions, see manufacturer website for details
Buy the Samtec SHF10501L – Reliable Surface-Mount Connectors for Industrial Applications
Order the Samtec SHF10501L connector today to ensure robust and dependable electrical connections in your industrial and electronic projects. Designed with high-quality materials including liquid crystal polymer insulators and phosphor bronze terminals, it offers excellent performance within a wide temperature range. Its RoHS compliance and lead-free solderability make it suitable for environmentally conscious manufacturing. Available in various pin counts and lengths, this connector ensures versatile integration into your PCBs, supporting demanding industrial and electronics applications with confidence and ease.
Buy Samtec SHF10501L now and experience unmatched reliability and performance in your electronic and industrial systems.
Frequently Asked Questions
Where can I buy SAMTEC SHF10501LDSM?
You can click on the BUY or RFQ button to purchase SHF10501LDSM from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SHF10501LDSM?
You can download the SHF10501LDSM datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SHF10501LDSM?
SAMTEC
