SAMTEC SHF10801LDTH Surface Mount Connector
The Sh F series connectors are high-performance surface-mount connectors featuring a black liquid crystal polymer insulator and phosphor bronze terminals with tin or gold plating. Designed for reliable electrical connections in demanding environments, they operate effectively from -55°C to +125°C. These connectors are RoHS compliant, lead-free, and solderable, with SMT lead coplanarity of 0.10 mm. Compatible with various sizes and configurations, they are ideal for compact electronic assemblies requiring precise pin alignment, durability, and high-temperature resistance. They meet quality standards and are suitable for demanding industrial and electronic applications.
SAMTEC SHF10801LDTH Surface Mount Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50μ" Ni
- Operating Temperature Range: -55°C to +125°C
- RoHS Compliant: Yes
- Processing: Lead-Free Solderable
- SMT Lead Coplanarity: 0.10 mm
- Sizes Available: 13, 17, 20, 25 pins
- Contact Arrangement: Pin-to-Pin
- Compatibility: ESHF series with SHF series, but not compatible with strain relief options
Buy the Samtec SHF – Reliable Surface-Mount Connectors for Industrial Applications
Purchase the Samtec Surface Mount Connector Series SHF 10801LDTH online today and enhance your electronic assemblies with reliable, high-performance connections. These connectors feature a robust liquid crystal polymer insulator, phosphor bronze terminals, and gold or tin plating, ensuring excellent electrical conductivity and durability in harsh environments. Operable from -55°C to +125°C, they are RoHS compliant, lead-free, and designed for precise SMT placement with 0.10 mm coplanarity. Perfect for demanding industrial and electronic applications requiring high-temperature resilience, long-term reliability, and compact design.
Order your Samtec Series SHF 10801LDTH today and give your electronic projects the dependable connection quality they deserve.
Frequently Asked Questions
Where can I buy SAMTEC SHF10801LDTH?
You can click on the BUY or RFQ button to purchase SHF10801LDTH from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SHF10801LDTH?
You can download the SHF10801LDTH datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SHF10801LDTH?
SAMTEC
