SAMTEC SMM11002SD PCB Connector
The SMM-110-02-L-S is a high-reliability, liquid crystal polymer insulated connector designed for PCB applications. It features four-point redundancy with BeCu contacts, gold or tin plating, and a simple insertion and withdrawal force suitable for demanding electronic systems. The connector supports operating temperatures from -55°C to +125°C, handles up to 3.2 A per pin, and is RoHS compliant. Ideal for PCB interconnects requiring durability, low contact resistance, and excellent performance in industrial environments, featuring a 0.0787-inch pitch and extended life design for long-term reliability.
SAMTEC SMM11002SD PCB Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: BeCu
- Plating: Sn or Au over 50u" Ni
- Current Rating: 3.2 A per pin
- Voltage Rating: 350 Vac
- Operating Temp Range: -55°C to +125°C
- Contact Resistance: 10 mΩ (3.56 mm)
- Insertion Depth: 140"
- Insertion Force: 0.42 N (2.00 mm pitch)
- Withdrawal Force: 0.42 N (single contact)
- RoHS Compliant: Yes
- Processing: Lead-Free Solderable
- Number of Positions: 2.00" pitch with multiple options
- Dimensions: 0.0787" pitch, length varies with options
Buy the Samtec SMM-110-02-L-S – Reliable PCB Connector for Industrial Applications
Discover the SMM-110-02-L-S high-reliability PCB connector designed for demanding industrial applications. Featuring BeCu contacts, gold or tin plating, and a 0.0787-inch pitch, it ensures excellent electrical performance and durability. Suitable for operating temperatures from -55°C to +125°C and rated at 3.2 A per pin, this connector also meets RoHS compliance standards. Its design allows for easy insertion and long-term service in complex electronic systems, making it an ideal choice for engineers seeking performance and longevity.
Buy Samtec SMM-110-02-L-S now and experience unmatched reliability and performance in PCB interconnects with extended life and high durability.
Frequently Asked Questions
Where can I buy SAMTEC SMM11002SD?
You can click on the BUY or RFQ button to purchase SMM11002SD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SMM11002SD?
You can download the SMM11002SD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SMM11002SD?
SAMTEC
