SAMTEC SQT11001LD Electrical Connector
The product is a high-reliability, RoHS-compliant electrical connector designed for vertical and right-angle applications, featuring black liquid crystal polymer insulation and phosphor bronze contacts with Sn or Au plating over Ni. It operates within a temperature range of -55°C to +125°C, with a contact resistance of 10 milliohms, current rating of 5.1 A, and voltage rating of 450 VAC when mated with specified headers. The connector supports up to 100 insertion cycles, has an insertion depth adjustable from 2.62 mm to 5.03 mm, and includes optional lead plating and optional RoHS options. Suitable for demanding electronic assemblies requiring reliable, corrosion-resistant connections with ease of installation.
SAMTEC SQT11001LD Electrical Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Sn or Au over 50u" Ni
- Current Rating: 5.1 A
- Voltage Rating: 450 VAC
- Operating Temperature Range: -55°C to +125°C
- Contact Resistance: 10 milliohms
- Insertion Depth: 2.62 mm to 5.03 mm
- Insertion Force: 402 (1.11 N) average
- Normal Force: 60 grams (0.59 N) average
- Withdrawal Force: 3.07 (0.83 N) average
- Max Cycles: 100 insertion cycles
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Surface Finishing: Matte Tin or Gold
Buy the Buy Samtec SQT-107-02-L-S Part Number SQT11001LD Online
Purchase the Samtec SQT series connector online today to ensure precision and durability in your electronic assemblies. This high-quality connector features black liquid crystal polymer insulation, phosphor bronze contacts with Sn or Au plating over Ni for excellent corrosion resistance, and supports operational temperatures from -55°C to +125°C. With a current rating of 5.1 A, voltage capacity of 450 VAC, and up to 100 insertion cycles, it offers reliable performance for demanding applications. Its RoHS compliance guarantees environmentally safe manufacturing, making it a smart choice for professionals seeking dependable, high-performance electronic components.
Get Samtec SQT-107-02-L-S today—designed for reliable connections with high-temperature resistance and corrosion protection.
Frequently Asked Questions
Where can I buy SAMTEC SQT11001LD?
You can click on the BUY or RFQ button to purchase SQT11001LD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SQT11001LD?
You can download the SQT11001LD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SQT11001LD?
SAMTEC
