SAMTEC SQT11501LD industrial connector
The SQT11501LD is a high-reliability, vertical and right-angle connector series designed for industrial applications. Constructed with black liquid crystal polymer insulators and phosphor bronze contacts, it offers excellent durability, RoHS compliance, and lead-free solderability. The connector features a 2.00 mm pitch, operates within a temperature range of -55°C to +125°C, and supports up to 100 mating cycles. With optional gold or tin plating, it ensures optimal conductivity and corrosion resistance for demanding electronic and industrial systems.
SAMTEC SQT11501LD industrial connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Sn or Au over 50u" (1,27 um) Ni
- Voltage Rating: 450 VAC
- Current Rating: 5.1 A per pin
- Temperature Range: -55°C to +125°C
- Contact Resistance: 10mΩ
- Insertion Depth: 2.62 mm to 5.03 mm
- Insertion Force: 402 (1.11 N) average
- Normal Force: 60 grams (0.59 N) average
- Withdrawal Force: 3.07 (0.83 N) average
- Max Cycles: 100
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Pitch: 2.00 mm (.0787")
- Surface Finish Options: Gold or Tin plating
- Mounting Style: Vertical and Right Angle
- Compatibility: Mates with multiple rows, supporting various length options
Buy the Samtec SQT11501LD – Reliable Connectors for Industrial Applications
Purchase the Samtec SQT11501LD connector online today and experience reliable performance in industrial applications. Crafted with durable materials like liquid crystal polymer and phosphor bronze contacts, this connector supports temperatures from -55°C to +125°C and up to 100 mating cycles. It features gold or tin plating options for enhanced conductivity and corrosion resistance. Designed for vertical and right-angle mounting, it ensures easy installation and secure connections in demanding environments. Order now to have this essential component delivered swiftly for your project needs.
Order your Samtec Series SQT11501LD connector today and ensure your industrial systems benefit from dependable, high-quality electrical connections.
Frequently Asked Questions
Where can I buy SAMTEC SQT11501LD?
You can click on the BUY or RFQ button to purchase SQT11501LD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SQT11501LD?
You can download the SQT11501LD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SQT11501LD?
SAMTEC
