SAMTEC SQW11301LD008 Rugged Connector System
The SQW-112 series are cost-effective rugged sockets suitable for a range of PCB applications. These connectors feature a choice of configurations from two to six rows, with options for surface mount or through-hole mounting. Made from black liquid crystal polymer insulator and phosphor bronze contacts, they are RoHS compliant and offer high durability with tin or gold plating. Operating voltage is up to 281 VAC, with an operating temperature range suitable for demanding environments. They are designed for easy insertion and removal, making them ideal for rugged electronic systems requiring reliable connections and long service life.
SAMTEC SQW11301LD008 Rugged Connector System Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Sn or Au over contact
- Voltage Rating: 281 VAC mated with TMM; 250 VAC mated with TMMH
- Operating Temperature Range: 0°C to 105°C
- Insertion Depth: 0.787 inches (2.62 mm)
- Max Cydess: >75
- RoHS Compliant: Yes
- Processing: Lead-Free Solderable, Surface Mount or Through-Hole options
- Number of Positions: 2 to 28 positions
- Dimensions vary with configuration, pitch options available from 0.049 to 0.300 inches
Buy the Samtec Series SQW Cost-Effective Rugged Sockets: SQW-112-01-F-D-VS-LC
Enhance your electronic assembly with the durable and versatile rugged connector system from Samtec. Designed for reliability in harsh conditions, these sockets feature multiple configurations, RoHS compliance, and high-quality materials like phosphor bronze contacts and liquid crystal polymer insulators. Suitable for surface mount or through-hole mounting, they support voltages up to 281 VAC and operate across a temperature range of 0°C to 105°C. Easy to install, maintain, and suitable for high-reliability applications, these connectors ensure long-lasting performance in rugged electronic environments.
Get Samtec SQW-112 series rugged sockets today—built for reliable PCB connection in demanding environments.
Frequently Asked Questions
Where can I buy SAMTEC SQW11301LD008?
You can click on the BUY or RFQ button to purchase SQW11301LD008 from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SQW11301LD008?
You can download the SQW11301LD008 datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SQW11301LD008?
SAMTEC
