SAMTEC SSQ10601GS Socket Strip
The SSQ-106-01-G-S is a 6-pole, single-row 2.54mm through-hole socket strip with a black color finish. It features 20-micrometer gold-plated phosphor bronze contacts and an LCP insulator. The socket provides standard and low insertion force contacts with 0.025-inch (0.635 mm) square tails, suitable for self-nesting applications. It has a current rating of 6.3A, a contact resistance of 10 milliohms, and is lead-free, solderable, and compatible with a variety of series connectors. Typically used in industrial applications.
SAMTEC SSQ10601GS Socket Strip Specifications:
- Number of Poles: 6
- Pitch: 2.54 mm
- Contact Material: Phosphor Bronze
- Plating: 20-micrometer gold
- Insulator Material: Liquid Crystal Polymer (LCP)
- Current Rating: 6.3A per pin
- Contact Resistance: 10 milliohms
- Voltage Rating: 550 VAC
- Insertion Depth: 0.145" to 0.250" (3.68 mm to 6.35 mm)
- Insertion Force: standard 6 oz (1.67 N), low insertion force 2.6 oz (0.72 N)
- Withdrawal Force: standard 5 oz (1.39 N), low insertion force 2.9 oz (0.81 N)
- Operating Temp Range: -55°C to +125°C with gold plating
- RoHS Compliant: Yes
- Lead-Free: Yes
- Solderable: Yes
- Max Cycles: 100
- Dimensions: 2.54 mm pitch, 6-pole, single-row
Buy the Samtec Series Socket Strip: SSQ-106-01-G-S
Purchase the Samtec SSQ-106-01-G-S socket strip online and benefit from high-quality, gold-plated contacts, robust insulator, and excellent current handling. Designed for easy installation with low insertion force options, this 6-pole, 2.54mm pitch socket strip ensures reliable connections in industrial, automation, and electronic applications. Its lead-free, RoHS-compliant construction guarantees sustainability and safety. Secure your inventory today and enhance your manufacturing process with this durable, high-performance socket strip that meets industry standards and technical specifications.
Buy Samtec SSQ-106-01-G-S socket strip now and experience unmatched reliability and performance in your industrial and electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC SSQ10601GS?
You can click on the BUY or RFQ button to purchase SSQ10601GS from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSQ10601GS?
You can download the SSQ10601GS datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSQ10601GS?
SAMTEC
