SAMTEC SSW10301GD High-Current Socket
The SSW-125-01-G-S is a high-quality through-hole socket designed for reliable electrical connections in various electronic applications. Constructed with black Liquid Crystal Polymer insulators and phosphor bronze contacts, it features gold plating for enhanced conductivity and corrosion resistance. The socket supports a current rating of 47 A, withstands operating temperatures from -55°C to +125°C depending on plating, and offers diverse insertion depths, row options, and lead styles. RoHS compliant and lead-free, it ensures high performance in demanding industrial environments for power and signal connections.
SAMTEC SSW10301GD High-Current Socket Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Gold or Tin with Ni layer
- Current Rating: 47 A
- Operating Temperature: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Insertion Depth: 3.68 mm to 6.35 mm
- Voltage Rating: 465 VAC / 655 VDC
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Row Options: -S, -D, wave only options
- Lead Styles: Single, Double, Triple leads, straight or right-angle versions
- Dimensions and sizes vary with multiple options and lengths, suitable for power and signal interconnections in industrial electronics.
- Compatible with: TSW, MTSW, MTLW series mates
- Temperature Rating: -55°C to +125°C (depending on plating)
Buy the Buy Samtec SSW-125-01-G-S Part Number SSW10301GD Online
Enhance your electronic assembly with the high-current socket designed for reliable power and signal transfer. Featuring durable Liquid Crystal Polymer insulation, phosphor bronze contacts, and gold plating for optimal conductivity, this socket supports up to 47 A current and operates efficiently between -55°C to +125°C. Its versatile insertion depths and lead styles accommodate various assemblies. Fully RoHS compliant and lead-free, it's suitable for demanding industrial applications. Order online now to benefit from quick delivery and expert support for your electrical and electronic needs.
Order your Samtec Series SSW-125-01-G-S socket today and ensure dependable power and signal connections in your electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC SSW10301GD?
You can click on the BUY or RFQ button to purchase SSW10301GD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW10301GD?
You can download the SSW10301GD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW10301GD?
SAMTEC
