SAMTEC SSW10402SDRA High-Temperature Socket
The SSW-125-01-G-S is a through-hole socket featuring a black Liquid Crystal Polymer insulator and phosphor bronze contacts plated with 50 microinches of gold over 1.27 micrometers of nickel. Designed for high-temperature operation, it accommodates 47 pins with a maximum current rating of 6.3 A per pin and an operating temperature from -55°C to +105°C. Its compact, square tail design ensures reliable electrical connections in electronic assemblies, complying with RoHS standards and suited for applications requiring durable, solderable connections with a high voltage rating of up to 465 VAC and 655 VDC.
SAMTEC SSW10402SDRA High-Temperature Socket Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Gold over Nickel, 50 microinches of gold
- Current Rating: 6.3 A per pin
- Operating Temperature: -55°C to +105°C
- Voltage Rating: 465 VAC / 655 VDC
- Number of Pins: 47
- RoHS Compliant: Yes
- Insertion Depth: 3.68 mm (0.145 inch)
- Lead-Free Solderable: Yes
- Maximum Power: Not specified
- Standard Dimensions: Square tail 2.54 mm pitch, 0.10 inch spacing
- Certifications: RoHS
Buy the Buy Samtec SSW-125-01-G-S Part Number SSW10402SDRA Online
Purchase the Samtec high-temperature socket online today for dependable connections in demanding environments. Featuring gold-plated contacts, a robust square tail design, and RoHS compliance, this socket offers 47 pins, a current rating of 6.3 A per pin, and an operating range of -55°C to +105°C. Its insulator made of black Liquid Crystal Polymer ensures durability and excellent thermal stability. Ideal for engineers and technicians needing a reliable, solderable connection solution, the socket guarantees long-lasting performance with a voltage rating of 465 VAC and 655 VDC, making it perfect for advanced electronic assemblies.
Get Samtec SSW-125-01-G-S today—built for high-temperature durability and reliable electrical performance in your applications.
Frequently Asked Questions
Where can I buy SAMTEC SSW10402SDRA?
You can click on the BUY or RFQ button to purchase SSW10402SDRA from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW10402SDRA?
You can download the SSW10402SDRA datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW10402SDRA?
SAMTEC
