SAMTEC SSW10802SMSRA Power Socket
This through-hole, 2.54 mm (0.100 inch) pitch socket features a black liquid crystal polymer insulator with optional high-temperature thermoplastic. Made of phosphor bronze contact material, it includes gold or tin plating, and supports current ratings up to 6.3 A per pin with a maximum operating temperature of 125°C. Designed for reliable power connections, it offers straight or right-angle configurations, various plating options, and compatible mate components, making it suitable for high-performance electronic assemblies requiring robust and durable socket connections.
SAMTEC SSW10802SMSRA Power Socket Specifications:
- Pitch: 2.54 mm (0.100 inch)
- Insulator Material: Black Liquid Crystal Polymer or High Temperature Thermoplastic
- Contact Material: Phosphor Bronze
- Plating: Gold or Tin
- Gold Plating Thickness: 50 µ-inch (1.27 µm)
- Current Rating: 6.3 A per pin
- Operating Temperature Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Voltage Rating: 465 VAC / 655 VDC
- Insertion Depth: 3.68 mm (for standard), 6.35 mm
- Standard Force: 125 grams (4.4 N)
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Configuration Options: Straight or right-angle, multiple plating options
- Compatible Mates: TSW, MTSW, ZW, TSS, ZSS, TSM, TSSH, HTSS
Buy the Samtec Series Power Socket: SSW10802SMSRA
Elevate your electronic assemblies with the high-quality power socket featuring a 2.54 mm pitch, durable phosphor bronze contacts, and versatile plating options. Designed for reliable power and signal connections, this socket supports current ratings up to 6.3 A per pin, with an operating temperature range from -55°C to +125°C. Its robust construction and RoHS compliance ensure long-lasting performance in demanding environments. Perfect for mission-critical applications where secure and stable connections are essential for optimal device operation.
Buy Samtec SSW10802SMSRA power socket now and experience unmatched reliability and performance in electronic power connections.
Frequently Asked Questions
Where can I buy SAMTEC SSW10802SMSRA?
You can click on the BUY or RFQ button to purchase SSW10802SMSRA from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW10802SMSRA?
You can download the SSW10802SMSRA datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW10802SMSRA?
SAMTEC
