SAMTEC SSW11701SS Through-Hole Socket
This high-quality through-hole socket features a 2.54 mm (.100 inch) pitch with 36 pins maximum. Crafted with black high-temperature insulator material and phosphor bronze contacts, it offers reliable electrical connections. The socket supports a current rating of 4.7A per pin and operates within a temperature range of -55 °C to +105 °C. With optional plating and configurations for straight or right-angle mounting, it is suitable for connecting multiple leads in various electronic assemblies, providing durability, precision, and ease of installation for industrial and electronic applications.
SAMTEC SSW11701SS Through-Hole Socket Specifications:
- Pitch: 2.54 mm (.100 inch)
- Number of Pins: Up to 36
- Insulator Material: Black High Temperature
- Contact Material: Phosphor Bronze
- Plating: 0.50 μm Ni, Gold flash on contact, optional other platings
- Current Rating: 4.7A per pin
- Voltage Rating: Not specified
- Operating Temperature Range: -55 °C to +105 °C
- Mounting: Through-hole with options for straight or right-angle mounting
- Max Insertion Force: 22-24 grams depending on configuration
- Lead Spacing: 2.54 mm (.100 inch)
- Configurations: Single, double, triple row options, with optional notch or other features
Buy the Samtec Series SSW Through-Hole Socket: SSW-117-01-SS
Purchase the Samtec Series SSW through-hole socket today and enjoy the benefits of high durability, precise 2.54 mm pitch, and versatile configurations. Designed for industrial and electronic applications, this socket supports up to 36 pins and a current rating of 4.7A per pin, with an environment-friendly lead-free, gold flash plating option. Ideal for PCB connections, it operates within a temperature range of -55°C to +105°C, with optional configurations for straight or right-angle mounting, ensuring dependable performance under demanding conditions.
Order your Samtec Series SSW SSW-117-01-SS through-hole socket today and ensure reliable, high-quality connections for your electronic projects.
Frequently Asked Questions
Where can I buy SAMTEC SSW11701SS?
You can click on the BUY or RFQ button to purchase SSW11701SS from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW11701SS?
You can download the SSW11701SS datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW11701SS?
SAMTEC
