SAMTEC SSW12501SS Through-Hole Socket
The SSW-125-01-G-S is a high-performance through-hole socket with a 2.54 mm pitch, designed for reliable electronic connections in industrial applications. Featuring a black Liquid Crystal Polymer insulator and phosphor bronze contact material, it offers excellent thermal stability and durability. Plated with gold or tin for optimized conductivity and corrosion resistance, it supports current ratings up to 6.3 A per pin and voltage ratings up to 465 VAC. Suitable for various environmental conditions, it ensures dependable performance in complex electronic assemblies, making it ideal for power and signal connections.
SAMTEC SSW12501SS Through-Hole Socket Specifications:
- Pitch: 2.54 mm
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Au or Sn over Ni
- Current Rating: 6.3 A per pin
- Voltage Rating: 465 VAC / 655 VDC
- Operating Temperature Range: -55 °C to +125 °C with gold, -55 °C to +105 °C with tin
- Insertion Depth: 3.68 mm (0.145 inches), 6.35 mm (0.25 inches)
- Standard Force: 125 grams (4.4 N)
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Applicable Rows: -S, -D, -P, -T, -Q options
- Durability: Designed for reliable repeat connections
- Compatibility: Mates with specified Samtec series connectors
Buy the Samtec SSW12501SS – Reliable Power and Signal Socket for Industrial Applications
Enhance your electronic assemblies with the high-quality Samtec through-hole socket. Featuring a 2.54 mm pitch, gold or tin plating, and robust design, this socket ensures reliable power and signal connections in industrial environments. Rated up to 6.3 A per pin and supporting voltage up to 465 VAC, it offers excellent thermal stability from -55°C to +125°C. Easy to install and compatible with various Samtec connectors, this socket is your ideal choice for durable, high-performance electronic projects. Purchase online now for fast delivery and dependable operation.
Order your Samtec Series SSW12501SS power and signal socket today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy SAMTEC SSW12501SS?
You can click on the BUY or RFQ button to purchase SSW12501SS from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part SSW12501SS?
You can download the SSW12501SS datasheet or visit the SAMTEC website for support.
Who is the manufacturer of SSW12501SS?
SAMTEC
