SAMTEC SSW12502GS microchip socket
The SSW-125-02-G-S is a through-hole socket featuring black liquid crystal polymer insulator and phosphor bronze contacts with gold or tin plating. It supports an operating temperature range of -55°C to +125°C with gold and -55°C to +105°C with tin, offering a current rating of 6.3 A per pin and voltage rating of 465 VAC / 655 VDC. Suitable for board mounting applications, it offers various lead and row options, with RoHS compliance and lead-free soldering suitability, ideal for high-temperature and reliable electronic connections.
SAMTEC SSW12502GS microchip socket Specifications:
- Insulator Material: Black Liquid Crystal Polymer or Black High Temperature Thermoplastic
- Contact Material: Phosphor Bronze
- Plating Options: Gold (Au) or Tin (Snover), 50 yt" Nickel underplate
- Current Rating: 6.3 A per pin
- Voltage Rating: 465 VAC / 655 VDC
- Operating Temperature Range: -55 °C to +125 °C with Gold, -55 °C to +105 °C with Tin
- Insertion Depth: 3.68 mm (Ms), 6.35 mm (Normal)
- Lead Option: Single, Double, or Triple Row, Straight or Right-Angle
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Certifications: Meets quality recognitions, customizable per customer specifications
- Other Features: RoHS compliant, lead-free, various plating and row options, suitable for high-current applications
Buy the Samtec Series SSW Through-Hole Socket: SSW12502GS
Order the Samtec SSW12502GS microchip socket online today and enjoy a highly reliable, RoHS-compliant connection solution. Designed for high temperatures and demanding environments, it features gold or tin plating for excellent contact durability. With a current capacity of 6.3 A per pin and voltage ratings up to 465 VAC, this socket offers versatile options for row and lead configurations, ensuring secure high-quality electrical connections. Perfect for engineers needing durable and precise electronic interconnections in various industrial applications.
Get Samtec SSW12502GS today—built for high-current reliability and demanding electronic connections.
