SAMTEC TFM10501SDWT Rugged Terminal Strip
The TFM series Rugged Tiger Eye™ Terminal Strip offers high reliability with a multi-finger BeCu contact system suitable for high cycle applications. It supports surface mount and through-hole terminations with options for vertical, right-angle, or horizontal orientations, ensuring flexible PCB integration. The terminal includes features such as optional alignment pins, locking clips, dual screw-downs, or weld tabs for increased ruggedness. Its shrouded body enables blind mating, and it’s compatible with Tiger Eye™ contact sockets and cable assemblies. Available in various stack heights with rugged mounting options like screw down or solder nail, ideal for industrial use. An Extended Life Product™ variant ensures long-term durability.
SAMTEC TFM10501SDWT Rugged Terminal Strip Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Au or Sn over Ni (1.27 um)
- Current Rating: 3.2A per pin
- Voltage Rating: 250 VAC with SFM
- Operating Temp Range: 55°C to +125°C
- RoHS Compliant: Yes
- Application: Surface-mount or through-hole termination, blind mating, rugged industrial environments, multiple orientations, locking, weld tab, solder nail options
- Stack Heights: 25mm to 50mm depending on model
- Pin Count: 5 to 50 positions
- Size: 1.27 mm pitch, 0.050" pitch options
- Compatibility: Supports Tiger Eye™ contact sockets and cable assemblies
- Features: Shrouded body, optional alignment pin, locking clip, dual screw-down, weld tab, extended life option
Buy the Buy Samtec TFM Series Rugged Terminal Strip Part Number TFM10501SDWT Online
Purchase the Samtec TFM series Rugged Terminal Strip online today for high cycle reliability and versatile PCB mounting options. Its durable BeCu contact system, shrouded body for blind mating, and multiple orientation choices ensure compatibility with demanding industrial applications. Features like optional locking clips, weld tabs, and solder nail options enhance ruggedness. Available with various stack heights and pin counts from 5 to 50, this terminal strip delivers exceptional performance and longevity. Secure your precision PCB connections efficiently—order now for fast delivery and expert support.
Get Samtec TFM10501SDWT today—designed for high reliability, rugged industrial environments, and long-lasting durability.
Frequently Asked Questions
Where can I buy SAMTEC TFM10501SDWT?
You can click on the BUY or RFQ button to purchase TFM10501SDWT from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part TFM10501SDWT?
You can download the TFM10501SDWT datasheet or visit the SAMTEC website for support.
Who is the manufacturer of TFM10501SDWT?
SAMTEC
