SAMTEC TFM10701LDWT High-Density Connector
The TFM10701LDWT is a rugged, high-density, four-row connector designed for reliable electrical connections in industrial and electronic applications. It features options such as screw-down, locking clip, friction latching, and weld tab ruggedizing, with surface mount or through-hole tails. Suitable for both board and cable assemblies, it offers polarization, keying, and various lead styles including right-angle and elevated configurations, accommodating multiple contact positions and configurations. Made from durable materials like BeCu, phosphor bronze, and insulating compounds, it ensures long-lasting performance with a voltage rating of 250VAC and a lifecycle of 10,000 cycles, ideal for demanding environments.
SAMTEC TFM10701LDWT High-Density Connector Specifications:
- Pitch: 1.27 mm (0.050 inches)
- Contact Material: BeCu, Phosphor Bronze
- Contact Plating: Au or Sn over 50μm Ni (ELP™ plating available)
- Operating Voltage: 250 VAC
- Cycle Life: 10,000 cycles
- Mounting Options: Surface mount, through-hole
- Lead Styles: T/H, SMT, right-angle, elevated, dual screw down, weld tab
- Number of Positions: 5 to 50 positions, single or double row configurations
- Material: Insulating LCP, Polyimide film for pick & place pads
- Insulation Resistance: Not specified
- Environmental Ratings: Not specified
- Compatibility: Board mates SFM, SFMC, SFML; Cable mates SFSD
- Dimensions: Various, with mated heights from 6.35 mm to 11.81 mm depending on options
- Certifications: Not specified
Buy the Buy Samtec TFM10701LDWT Part Number TFM10701LDWT Online
Order the Samtec TFM10701LDWT connector online today to ensure reliable, high-density connections for your industrial or electronic project. Designed with rugged options including screw-down, locking clip, and weld tab ruggedizing, it supports surface mount and through-hole mounting for versatile assembly. With high durability, a 10,000 cycle lifespan, and operating voltage up to 250VAC, this connector guarantees long-term performance in demanding environments. Perfect for systems requiring reliable contact integrity and flexible configuration, make your purchase today for quality assurance and seamless integration.
Get Samtec TFM10701LDWT today—built for rugged industrial applications and long-lasting durability.
Frequently Asked Questions
Where can I buy SAMTEC TFM10701LDWT?
You can click on the BUY or RFQ button to purchase TFM10701LDWT from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part TFM10701LDWT?
You can download the TFM10701LDWT datasheet or visit the SAMTEC website for support.
Who is the manufacturer of TFM10701LDWT?
SAMTEC
