SAMTEC TLE10701GDVAKTR Pass-Through Connector
The TLE107-01-G-DV is a versatile pass-through connector with micro pitch features, suitable for PCB mounting in demanding applications. Made from black liquid crystal polymer insulator and phosphor bronze contacts with gold over nickel plating, it offers a current rating of 3.2A per pin and operates within -55°C to +125°C. Its design includes an insertion depth of approximately 2.08mm to 3.33mm, with low insertion and withdrawal forces, RoHS compliance, and SMT lead coplanarity. Ideal for industry-standard, high-reliability PCB connections in various electronic systems.
SAMTEC TLE10701GDVAKTR Pass-Through Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Contact Material: Phosphor Bronze
- Plating: Au over 50p" Nickel (1.27µm)
- Current Rating: 3.2A per pin
- Operating Temperature Range: -55°C to +125°C
- Insertion Depth: 2.08mm to 3.33mm
- Insertion Force: 2.75 oz (0.76 N) avg.
- Withdrawal Force: 0.80 oz (0.22 N) avg.
- RoHS Compliant: Yes
- Processing: Lead-Free, Solderable
- SMT Lead Coplanarity: Max 0.004" (0.10mm) to 0.006" (0.15mm)
- Design for pass-through applications with optional Pick & Place Pads
- Available with micro pitch and various lengths, styles, and options
Buy the Samtec TLE107-01-G-DV – Reliable PCB Pass-Through Connector for Industrial Applications
Elevate your PCB connections with the Samtec TLE107-01-G-DV, a high-quality pass-through connector designed for durability and precision. Crafted from advanced materials with gold plating for maximum conductivity and corrosion resistance, it ensures reliable operation in demanding environments. Its micro pitch design allows for compact, efficient circuit integration. Suitable for pass-through applications, it features low insertion and withdrawal forces, RoHS compliance, and SMT lead coplanarity. Perfect for high-volume manufacturing, this connector simplifies assembly and guarantees consistent electrical performance, making it an ideal choice for defense, aerospace, and industrial electronics.
Buy Samtec TLE107-01-G-DV now and experience unmatched reliability and performance in your PCB assembly and high-volume electronic manufacturing.
Frequently Asked Questions
Where can I buy SAMTEC TLE10701GDVAKTR?
You can click on the BUY or RFQ button to purchase TLE10701GDVAKTR from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part TLE10701GDVAKTR?
You can download the TLE10701GDVAKTR datasheet or visit the SAMTEC website for support.
Who is the manufacturer of TLE10701GDVAKTR?
SAMTEC
