SAMTEC TMM10301GS Low Profile SMT Header
The TMM Series Low Profile SMT Header is a robust, compact connector compatible with various mating components including CLT, SQT, SQW, and ESQT. Made from black liquid crystal polymer insulator and phosphor bronze terminal, it features optional gold or tin over nickel Plating for enhanced corrosion resistance. With a 2mm pitch and operating temperature range of -55°C to +105°C or +125°C depending on plating, it can handle up to 3.2 Amperes per pin at 450 VAC. Meets RoHS standards, suitable for space-constrained PCB applications requiring reliable electrical performance.
SAMTEC TMM10301GS Low Profile SMT Header Specifications:
- Pitch: 2mm
- Insulator Material: Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50u" Ni
- Current Rating: 3.2A per pin
- Voltage Rating: 450 VAC
- Operating Temp Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- RoHS Compliant: Yes
- Mating with: CLT, SQT, SQW, ESQT
- SMT Lead Coplanarity: <1 mm, max 0.006"
- Lead Style: SMT, optional pick & place pads, alignment pins, tape & reel packaging
- Certifications: RoHS
Buy the Samtec Series TMM Low Profile SMT Header: TMM10301GS
Purchase the Samtec TMM10301GS Low Profile SMT Header online today for reliable, space-efficient PCB connections. Featuring a 2mm pitch, RoHS compliance, and optional gold or tin plating, it handles 3.2 amperes per pin at 450 volts, ensuring excellent electrical performance. Its compact design and optional features like pick & place pads make it ideal for automated manufacturing. Trust Samtec's quality to enhance your electronic assemblies. Order now and enjoy fast delivery, dependable performance, and a solution crafted for demanding industrial applications.
Get Samtec TMM10301GS today—built for precision and long-lasting durability in compact PCB assemblies.
Frequently Asked Questions
Where can I buy SAMTEC TMM10301GS?
You can click on the BUY or RFQ button to purchase TMM10301GS from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part TMM10301GS?
You can download the TMM10301GS datasheet or visit the SAMTEC website for support.
Who is the manufacturer of TMM10301GS?
SAMTEC
