SAMTEC TMM10506LMDSM PCB Shunt Connector
The TMM series cable mates feature black liquid crystal polymer insulators and phosphor bronze terminals with Sn or Au plating over Ni. Designed for PCB applications, these shunt connectors support operating temperatures from -55°C to +125°C with gold plating and up to +105°C with tin. They have a 2.00 mm pitch, low profile design, optional pick-and-place pads, alignment pins, and tape & reel packaging. Suitable for RoHS-compliant and lead-free environments, they accommodate high current ratings up to 3.2A per pin with voltage ratings up to 281 VAC. Available in multiple configurations for reliable electrical connections.
SAMTEC TMM10506LMDSM PCB Shunt Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50 µm Ni
- Current Rating: 3.2A per pin (2 pins powered)
- Operating Temp Range: -55°C to +125°C with Gold, -55°C to +105°C with Tin
- Voltage Rating: 281 VAC mated with SQW; 250 VAC with SQT
- Pitch: 2.00 mm (0.0787 inches)
- Lead-Free Solderable: Yes
- Options: Pick & place pads, Alignment pins, Tape & reel packaging
- Profile: Low profile, approximately 1.27 mm (0.050 inches)
Buy the Samtec TMM-110-01-S-D-SM – Reliable PCB Shunt Connectors for Industrial Applications
Enhance your electronic assemblies with the reliable PCB shunt connectors from Samtec. Featuring a 2.00 mm pitch, RoHS compliance, and optional features like pick-and-place pads and tape & reel packaging, these connectors support high current ratings up to 3.2A per pin and operate within -55°C to +125°C. Their durable construction with phosphor bronze terminals and gold or tin plating ensures excellent performance in industrial environments. Perfect for manufacturing and automation systems that demand dependable electrical connections and easy assembly.
Order your Samtec Series TMM-110-01-S-D-SM today and give your PCB designs the dependable connectivity they deserve with premium low-profile connectors.
