SAMTEC TSH10501LD SMT Connector
The TSH-125 series is a high-quality, RoHS compliant, liquid crystal polymer insulator connector designed for SMT applications. Made from black LCP with phosphor bronze terminals, it features Sn or Au over 50 µ
SAMTEC TSH10501LD SMT Connector Specifications:
- Insulator Material: Black Liquid Crystal Polymer
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50 µ
- Ni
- Operating Temp Range: -55 °C to +125 °C with Gold, -55 °C to +105 °C with Tin
- RoHS Compliant: Yes
- Solderability: Lead-free solderable
- SMT Lead Coplanarity: 0.006 inches max
- No. of pins: 5, 10, 15, 20, 25, 30, 35, 40, 45
- Dimensions: 2.00 mm pitch, various lengths available
- Processing: Suitable for SMT assembly
- Note: Some lengths, styles, and options are non-standard, non-returnable
Buy the Buy Samtec TSH-125-01-T-DV Part Number TSH10501LD Online
Purchase the Samtec SMT connector today for reliable electrical connections, high temperature operation, and lead-free soldering compatibility. Designed with black liquid crystal polymer insulators and phosphor bronze terminals, it supports various pin configurations, ensuring a perfect fit for demanding electronic assembly applications. Its RoHS compliance and excellent coplanarity make it ideal for PCB assembly, providing durability and precision in electronic manufacturing. Secure your stock now and enjoy fast online ordering and delivery.
Get Samtec TSH-125-01-T-DV today—built for precision, high temperature resilience, and long-lasting durability.
Frequently Asked Questions
Where can I buy SAMTEC TSH10501LD?
You can click on the BUY or RFQ button to purchase TSH10501LD from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part TSH10501LD?
You can download the TSH10501LD datasheet or visit the SAMTEC website for support.
Who is the manufacturer of TSH10501LD?
SAMTEC
