Sensata - Crydom CXE240A5 Industrial Solid State Relay
The PCB Mount CXE240A5 is a solid-state relay designed for heavy industrial loads with a 5 A rating at 660 VAC. It features SCR output for reliable switching of resistive and inductive loads, with both AC and DC control options. This model supports zero-crossing and random-fire switching modes, ensuring versatile operation across various applications. Its compact design complies with IEC and CE standards, providing safe and efficient control for high-voltage circuits in industrial automation and power management systems.
Sensata - Crydom CXE240A5 Industrial Solid State Relay Specifications:
- Operating Voltage: 12-280 VAC (CX240x5), 48-530 VAC (CX380x5), 48-660 VAC (CX480x5)
- Maximum Load Current: 5 A
- Control Voltage Range: 3-15 VDC (CX240x5), 4-15 VAC (CX380x5), 15-32 VDC (CXE240A5), 90-140 VAC (CXE380D5), 18-36 VAC (CXE48005)
- Maximum Surge Current: 250 A for 16.6 msec
- Maximum Off-State Leakage Current: minimal at rated voltage
- Maximum On-State Voltage Drop: 14 Vpk
- Insulation Resistance: ≥ 1 GΩ at 500 VDC
- Dielectric Strength: 4000 Vrms input/output, Meets IEC standards
- Ambient Operating Temperature: -30°C to 80°C
- Weight: approximately 11 g
- Enclosure: Thermally conductive epoxy, IEC60335-1 compliant
Buy the Crydom Series Industrial Solid State Relay: CXE240A5
Purchase the Crydom CXE240A5 PCB mount solid-state relay online today to ensure reliable, fast switching of high-voltage loads. Designed for industrial automation, this relay offers 5 A rated at 660 VAC with AC and DC control options. Its compact waterproof design makes it ideal for harsh environments, providing zero-crossing or random-fire switching modes. Enjoy seamless integration, CE compliance, and robust performance. Order now to optimize your power control systems with this trusted industrial component for demanding applications.
Buy Crydom CXE240A5 now and experience unmatched reliability and performance in heavy industrial load switching with advanced control options.
Frequently Asked Questions
Where can I buy Sensata - Crydom CXE240A5?
You can click on the BUY or RFQ button to purchase CXE240A5 from an authorized Sensata - Crydom distributor.
How do I troubleshoot issues or seek technical support for part CXE240A5?
You can download the CXE240A5 datasheet or visit the Sensata - Crydom website for support.
Who is the manufacturer of CXE240A5?
Sensata - Crydom
