Sensata - Crydom HAC24D15010 Control Switch
The HAC Series Panel Mount is designed for controlling AC or DC loads with voltage ranges from 24 to 660 VAC. Capable of delivering up to 150 Arms, it offers zero voltage or instantaneous turn-on options, with built-in transient protection, a locking input connector, and optional thermal pads for enhanced thermal management. Suitable for industrial automation requiring reliable switching, the HAC Series adapts to various input control voltages from 4-32 VDC, 90-270 VAC, or 150-270 VAC, making it versatile for diverse applications. Its robust design ensures safe, efficient operation in demanding environments.
Sensata - Crydom HAC24D15010 Control Switch Specifications:
- Load Voltage Range: 24-660 VAC
- Output Rating: Up to 150 Arms
- Control Voltage Options: 4-32 VDC, 90-140 VAC, 150-270 VAC
- Transient Overvoltage: 600V or 1200V pk
- Maximum Load Current: 150 Amps
- Operating Voltage: 24-280 VAC or 48-660 VAC
- Maximum Surge Current: 1670-1750 Apk (1 cycle)
- Maximum Off-State Leakage Current: 1mA
- Maximum dv/dt: 500 V/μsec
- Wire Size Max: 2/0 AWG (solid/stranded)
- Output Terminal Nut Torque Range: 25.4-33.9 in-lb
- Dielectric Strength: Input/Output 3750 Vrms
- Ambient Operating Temperature: -30°C to 80°C
- Housing Material: PBT with 30% GF, UL 94V-0
- Mechanical Dimensions: Mounting holes 0.20 inch dia., overall dimensions approximately 3.62 x 4.12 inches
- Certifications: IEC 62314, IEC 61000-4 series, CE
Buy the Crydom Series HAC Control Switch: HAC24D150
Discover the highly reliable Crydom Series HAC24D150 control switch, designed for industrial automation and load switching. With a voltage range from 24 to 660 VAC, it provides up to 150 amps of load current, making it suitable for demanding environments. Features include zero voltage or instantaneous turn-on options, optional transient overvoltage protection, locking input connector, and optional thermal pads for improved thermal management. Its rugged construction ensures durability, safe operation, and versatility across diverse automation applications. Buy online today for dependable performance and easy integration into your systems.
Order your Crydom Series HAC24D150 Panel Mount Switch today and ensure reliable load control with advanced transient protection and high current capacity.
Frequently Asked Questions
Where can I buy Sensata - Crydom HAC24D15010?
You can click on the BUY or RFQ button to purchase HAC24D15010 from an authorized Sensata - Crydom distributor.
How do I troubleshoot issues or seek technical support for part HAC24D15010?
You can download the HAC24D15010 datasheet or visit the Sensata - Crydom website for support.
Who is the manufacturer of HAC24D15010?
Sensata - Crydom
