Sensata - Crydom M5060SB1200 Power Module
The M5060 Power Module series is designed for high surge current rectifier circuits with voltage ratings up to 600 VAC and a maximum DC output current of 100A at 85°C. Featuring advanced electrical specifications, it handles repetitive peak reverse voltages up to 1600 V and surge currents up to 1500 A. Suitable for industrial power control applications, it incorporates robust mechanical construction, thermal management, and UL recognition. Ideal for high-voltage rectification, these modules offer reliable performance in demanding environments, with efficient heat dissipation and compliance with safety standards.
Sensata - Crydom M5060SB1200 Power Module Specifications:
- Maximum DC Output Current: 100A at T= 85°C
- Maximum Voltage Drop: 1.35V @ 50A, 1N@ 100A
- Operating Junction Temperature Range: 40 - 125°C
- AC Line Voltage Options: 400 VAC, 600 VAC, 1000 VAC, 1200 VAC, 1400 VAC, 1600 VAC
- Repetitive Peak Reverse Voltage: 800 V to 1600 V depending on model
- Maximum Non-Repetitive Surge Current: 1500 A
- Insolation Voltage: 2500 Vrms
- Weight: 158g
- Thermal Resistance: 0.045°C/W
- Electrical Tolerance: ±0.02 inches (0.5 mm)
- Mechanical Dimensions: 1.625 inches (41.2 mm) length, mounting hole: 0.20 inches (5.1 mm) diameter
- Certification: UL Recognized E72445
- Environmental Compliance: Standard SJ/T11364—2006
Buy the Buy Crydom Power Module Part Number M5060SB1200 Online
Secure your high-voltage power control needs by purchasing the Crydom M5060SB1200 power module online today. Designed for industrial applications, it withstands voltages up to 1600 V and delivers 100 A at 85°C. Its robust construction ensures reliable performance in demanding environments, offering excellent thermal management and UL recognition. Simplify your procurement process with fast online ordering, ensuring you get premium quality power modules for your power rectification and industrial control projects promptly and efficiently.
Order your Crydom series M5060SB1200 power module today and ensure dependable high-voltage rectification with optimal surge current handling.
Frequently Asked Questions
Where can I buy Sensata - Crydom M5060SB1200?
You can click on the BUY or RFQ button to purchase M5060SB1200 from an authorized Sensata - Crydom distributor.
How do I troubleshoot issues or seek technical support for part M5060SB1200?
You can download the M5060SB1200 datasheet or visit the Sensata - Crydom website for support.
Who is the manufacturer of M5060SB1200?
Sensata - Crydom
