Song Chuan 852W1AFC124VDC Power Relay
The SONG CHUAN 852W-1A-F-C1-24VDC is a compact and reliable power relay designed for a variety of industrial applications. This relay offers a switching capacity of 25A at 250VAC and is approved by UL/CUL and VDE for safety and performance. Its quick connect terminals simplify installation, while its robust construction ensures long-term reliability in demanding environments. Ideal for HVAC systems, compressor controls, and other applications requiring frequent switching of inductive loads.
Song Chuan 852W1AFC124VDC Power Relay Specifications:
- Contact Material: AgSnO alloy
- Contact Resistance (Max): 30mΩ
- Operating Time (Max): 20ms
- Release Time (Max): 10ms
- Insulation Resistance (Min): 100MΩ
- Dielectric Strength: AC 1200V (Between open contacts), AC 3600V (Between contact and coil)
- Operating Ambient Temperature: -25 ~ +70°C
- Weight: Approx. 31.5g
- Rated Voltage: 5V, 6V, 9V, 12V, 24V, 48V
- Rated Current: 180mA - 19mA (depending on voltage)
- Coil Resistance: 27.8Ω - 2560Ω (depending on voltage)
- Max Continuous Coil Voltage: 150% of rated voltage at 70°C
- Pick Up Voltage: 75% of rated voltage at 23°C
- Drop Out Voltage: 10% of rated voltage at 23°C
- Power Consumption: Approx. 0.9W at rated voltage
- Contact Rating (Resistive Load): 25A 250VAC
- Contact Rating (Inductive Load): 20A 250VAC (Inrush 80A)
- Vibration Resistance: 10-50Hz, amplitude 1.0mm (Damage limits: 2.0mm)
- Shock Resistance: 10G (Damage limits: 100G)
- Mechanical Life Expectancy: 10,000,000 operations
- Electrical Life Expectancy: 100,000 operations
