SUSUMU KRL1220ECR082FT5 Low Resistance Chip Resistors
The KRL series consists of metal foil low resistance chip resistors designed for high current sensing applications. They feature a face-down construction with options for bottom or wrap-around terminals, and are available in sizes ranging from 0510 to 50110 with power ratings from 0.2W to 5W. These resistors operate across a wide temperature range up to 175°C for high temperature types and up to 155°C for low emf types, offering low resistance values from 5mΩ to 1000mΩ, suitable for automotive electronics and power conversion devices.
SUSUMU KRL1220ECR082FT5 Low Resistance Chip Resistors Specifications:
- Size: 0510 to 50110
- Power Ratings: 0.2W to 5W
- Resistance Range: 5mΩ to 1000mΩ
- Operating Temperature: -55°C to +175°C (high temp), -55°C to +155°C (low emf)
- Terminal Types: Bottom (D), Wrap Around (E)
- Construction: Face down with options for bottom or wrap terminal
- RoHS and Halogen Free compliant
- Resistance Value Tolerance: ±1% or ±2% (based on series)
- Application: Automotive electronics, power supply units, motor drives, inverters
Buy the KRL Series Low Resistance Chip Resistors: KRL1220E
Enhance your electronic designs with our high-quality low resistance chip resistors from the KRL series. Designed for high current sensing, these resistors feature robust construction, wide resistance and power ratings, and operate across a broad temperature spectrum up to 175°C. Available in multiple sizes and terminal types, they're perfect for automotive electronics, power supplies, and motor controls. Purchase online to ensure fast delivery and reliable performance for your industrial, automation, or power conversion projects.
Buy KRL1220E high current sensing resistors now and experience unmatched reliability and performance for your electronic applications.
Frequently Asked Questions
Where can I buy SUSUMU KRL1220ECR082FT5?
You can click on the BUY or RFQ button to purchase KRL1220ECR082FT5 from an authorized SUSUMU distributor.
How do I troubleshoot issues or seek technical support for part KRL1220ECR082FT5?
You can download the KRL1220ECR082FT5 datasheet or visit the SUSUMU website for support.
Who is the manufacturer of KRL1220ECR082FT5?
SUSUMU
