SUSUMU KRL1632ECR220FT5 High Resistance Metal Foil Resistor
The KRL series features metal foil low resistance chip resistors designed for high current sensing with short-side terminals. They are compliant with AEC-Q200 standards and available in various sizes including 0510, 0816, 1220, 1632, 2550, 3264, and 50110. These resistors operate at high temperatures up to 175°C with low emf options, offering excellent power handling from 0.2W to 5W and resistance values ranging from 5mΩ to 1000mΩ. Their face-down construction includes bottom or wrap-around terminals suited for automotive, power supply, inverter, and automation applications. They meet RoHS and halogen-free regulations, ensuring reliability and environmental safety.
SUSUMU KRL1632ECR220FT5 High Resistance Metal Foil Resistor Specifications:
- Size: 0510, 0816, 1220, 1632, 2550, 3264, 50110
- Power Ratings: 0.2W to 5W
- Resistance Range: 5mΩ to 1000mΩ
- Operating Temperature: Up to 175°C (high temp), up to 155°C (low emf)
- Terminal Types: Bottom terminal (D), Wrap around (E)
- Face down construction with options for lead configuration
- RoHS compliant, Halogen free
- Resistance series: E-6/E-12, customizable resistance values
- Dimensions vary per size, designed for high current sensing
- Suitable for automotive, power sources, inverters, automation devices
Buy the Buy Metal Foil Low Resistance Chip Resistors Part Number KRL1632ECR220FT5 Online
Purchase the high-performance metal foil low resistance chip resistor KRL1632ECR220FT5 online today to ensure superior current sensing and thermal stability. Perfect for automotive applications, power supplies, inverters, and automation systems, this resistor offers a wide resistance range from 5mΩ to 1000mΩ and power ratings up to 5W. Its robust face-down construction with options for bottom or wrap-around terminals guarantees reliable mounting and excellent thermal management. Enjoy fast delivery and ensure your projects benefit from top-quality, RoHS-compliant resistors designed for demanding environments.
Buy Metal Foil Low Resistance Chip Resistors KRL1632ECR220FT5 now and experience unmatched reliability and high-temperature performance.
Frequently Asked Questions
Where can I buy SUSUMU KRL1632ECR220FT5?
You can click on the BUY or RFQ button to purchase KRL1632ECR220FT5 from an authorized SUSUMU distributor.
How do I troubleshoot issues or seek technical support for part KRL1632ECR220FT5?
You can download the KRL1632ECR220FT5 datasheet or visit the SUSUMU website for support.
Who is the manufacturer of KRL1632ECR220FT5?
SUSUMU
